Parameters
1-20 Motor Power
Range:
[17] 15.00kW - 20 hp
[18] 18.5kW - 25 hp
[19] 22kW - 30 hp
[20] 30kW - 40 hp
[21] 37kW - 50 hp
[22] 45kW - 60 hp
[23] 55kW - 75 hp
[24] 75kW - 100 hp
[25] 90kW - 120 hp
[26] 110kW - 150 hp
1-22 Motor Voltage
Range: Function:
Size [50 - 1000 Enter the nominal motor voltage
related V] according to the motor nameplate data.
*
The default value corresponds to the
nominal rated output of the unit.
This parameter cannot be adjusted while
the motor is running.
1-23 Motor Frequency
Range: Function:
Size [20 - Select the motor frequency value from the
related 400 Hz] motor nameplate data.For 87 Hz operation
*
with 230/400 V motors, set the nameplate
data for 230V/50Hz. Adapt 4-14 Motor
Speed High Limit [Hz] and 3-03 Maximum
Reference to the 87Hz application.
NOTE
This parameter cannot be adjusted while the motor is
running.
1-24 Motor Current
Range: Function:
Size related [0.01 - 26.0 Enter the nominal motor current value
*
A] from the motor nameplate data. This
data is used for calculating motor
torque, motor thermal protection etc.
NOTE
This parameter cannot be adjusted while the motor is
running.
1-25 Motor Nominal Speed
Range:
Size related [100.0 -
*
60000.0 RPM]
VLT HVAC Basic Drive Programming Guide
Function:
Function:
Enter the nominal motor speed
value from the motor nameplate
data. This data is used for
calculating automatic motor
compensations.
®
MG.18.B1.02 - VLT is a registered Danfoss trademark
NOTE
This parameter cannot be adjusted while the motor is
running.
1-29 Automatic Motor Adaption (AMA)
Option: Function:
The AMA function optimizes dynamic motor
performance by automatically optimizing the
advanced motor 1-30 Stator Resistance (Rs) to
1-35 Main Reactance (Xh)) while the motor is
stationary.
[0] Off No function
*
[1] Enable Performs AMA of the stator resistance R
Complete stator leakage reactance X
AMA
reactance X
NOTE
Please note that terminal 27 Digital Input
(5-12 Terminal 27 Digital Input) has coast
inverse as default setting. This means that
AMA can not be performed if there is no
24V to terminal 27, so please connect
terminal 12 to terminal 27.
[2] Enable Performs a reduced AMA of the stator
Reduced resistance R
AMA option if an LC filter is used between the
frequency converter and the motor.
Activate the AMA function by pressing [Hand on] after
selecting [1] or [2]. After a normal sequence, the display will
read: "Press [OK] to finish AMA". After pressing the [OK] key
the frequency converter is ready for operation.
NOTE
•
For the best adaptation of the frequency converter,
run AMA on a cold motor
•
AMA cannot be performed while the motor is
running
•
AMA can not be performed on a motor with a
bigger power rating than the frequency converter,
e.g. when a 5.5kW motor is connected to a 4kW
frequency converter.
NOTE
Avoid generating external torque during AMA.
