Danfoss VLT HVAC Basic Drive Programming Manual page 44

Parameters
6-71 Terminal 45 Analog Output
Option: Function:
[101] Reference MinRef. - MaxRef.
[102] Feedback MinFB - MaxFB
[103] Motor current 0 - I
max
[106] Power 0 - P
nom
[139] Bus Control 0 - 100%
6-72 Terminal 45 Digital Output
Option:
[0] No operation
*
[1] Control ready
[2] Drive ready
[3] Drive ready/remote control
[4] Standby / no warning
[5] VLT running
[6] Running / no warning
[7] Run in range/no warning
[8] Run on ref/no warning
[9] Alarm
[10] Alarm or warning
[12] Out of current range
[13] Below current, low
[14] Above current, high
[21] Thermal warning
[22] Ready, no thermal warning
[23] Remote, ready, no thermal warning
[24] Ready, Voltage OK
[25] Reverse
[26] Bus OK
[35] External Interlock
[36] Control word bit 11
[45] Bus Control
[60] Comparator 0
[61] Comparator 1
[62] Comparator 2
[63] Comparator 3
[64] Comparator 4
[65] Comparator 5
[70] Logic rule 0
[71] Logic rule 1
[72] Logic rule 2
[73] Logic rule 3
[74] Logic rule 4
[75] Logic rule 5
VLT HVAC Basic Drive Programming Guide
6-72 Terminal 45 Digital Output
Option:
[80]
[81]
[82]
[83]
[160] No alarm
[161] Running reverse
[165] Local ref. active
[166] Remote ref. active
[167] Start command activ
Function:
[168] Drive in hand mode
Select the function of
[169] Drive in auto mode
Terminal 45 as a digital
[193] Sleep Mode
current output. See
[194] Broken Belt Function
also 6-70 Terminal 45
[196] Fire Mode
Mode. See
[198] Drive Bypass
5-40 Function Relay for
description of the
6-73 Terminal 45 Output Min Scale
choices.
Range:
0.0 %
6-74 Terminal 45 Output Max Scale
Range:
100.0
%
6-76 Terminal 45 Output Bus Control
Range:
0.0 %
®
MG.18.B1.02 - VLT is a registered Danfoss trademark
SL digital output A
SL digital output B
SL digital output C
SL digital output D
Function:
[0.0 - 200.0 Scale for the minimum output (0 or 4mA) of
*
%] the analogue signal at Terminal 45. Set the
value to be the percentage of the full range
of the variable selected in 6-71 Terminal 45
Analog Output.
Function:
[0.0 - Scale for the maximum output (20mA) of the
200.0 analog signal at Terminal 45. Set the value to be
*
%] the percentage of the full range of the variable
selected in 6-71 Terminal 45 Analog Output.
Current
(mA)
20
0/4
0%
Analogue
output
Min Scale
par. 6-73
[0.0 - 100.0 %]
*
Function:
3
Analogue 100% Variable
Output for
Max Scale output
par. 6-74 example:
Power
Function:
43
3
