Limits/Warnings; Digital In/Out - Danfoss VLT HVAC Basic Drive Programming Manual

Parameter Lists

5.1.6 4-** Limits/Warnings

Par. Parameter description
No. #
4-1* Motor Limits
4-10 Motor Speed Direction
4-12 Motor Speed Low Limit [Hz]
4-14 Motor Speed High Limit [Hz]
4-18 Current Limit
4-19 Max Output Frequency
5 5
4-5* Adj. Warnings
4-50 Warning Current Low
4-51 Warning Current High
4-58 Missing Motor Phase Function
4-6* Speed Bypass
4-61 Bypass Speed From [Hz]
4-63 Bypass Speed To [Hz]
4-64 Semi-Auto Bypass Set-up

5.1.7 5-** Digital In/Out

Par. Parameter description
No. #
5-0* Digital I/O mode
5-00 Digital Input Mode
5-03 Digital Input 29 Mode
5-1* Digital Inputs
5-10 Terminal 18 Digital Input
5-11 Terminal 19 Digital Input
5-12 Terminal 27 Digital Input
5-13 Terminal 29 Digital Input
5-4* Relays
5-40 Function Relay
5-9* Bus Controlled
5-90 Digital & Relay Bus Control
84
VLT HVAC Basic Drive Programming Guide
Default value
[2] Both directions
0.0 Hz
65.0 Hz
110.0 %
65.0 Hz
0.00 A
194.00 A
[1] On
0.0 Hz
0.0 Hz
[0] Off
Default value
[0] PNP
[0] PNP
[8] Start
[0] No operation
[2] Coast inverse
[14] Jog
ExpressionLimit
0.0 N/A
®
MG.18.B1.02 - VLT is a registered Danfoss trademark
2-set-up Change Conver-
during sion index
operation
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups TRUE
All set-ups FALSE
All set-ups TRUE
All set-ups TRUE
All set-ups FALSE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
2-set-up Change Conver-
during sion index
operation
1 set-up FALSE
1 set-up FALSE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
Type
- Uint8
-1 uint_16
-1 Uint16
0 uint_16
-1 Uint16
-2 uint_32
-2 uint_32
- Uint8
-1 uint_16
-1 uint_16
- Uint8
Type
- Uint8
- Uint8
- Uint8
- Uint8
- Uint8
- Uint8
- Uint8
0 uint_32
