Troubleshooting
No. Description
53 AMA motor too big
54 AMA motor too small
55 AMA Parameter out of range
56 AMA interrupted by user
57 AMA timeout
58 AMA internal fault
59 Current limit
60 External Interlock
66 Heat sink Temperature Low
69 Pwr Card Temperature
79 Illegal PS config
80 Drive Initialized to Default Value
87 Auto DC Braking
95 Broken Belt
201 Fire Mode
202 Fire M Limits Exceeded
250 New spare parts
251 New Type Code
Table 4.1 Alarm/Warning code list
(X) Dependent on parameter
A trip is the action when an alarm has appeared. The trip will
coast the motor and can be reset by pressing the reset
button or make a reset by a digital input (parameter group
5-1* [1]). The original event that caused an alarm cannot
damage the frequency converter or cause dangerous
conditions. A trip lock is an action when an alarm occurs,
which may cause damage to frequency converter or
connected parts. A Trip Lock situation can only be reset by a
power cycling.
LED indication
Warning
Alarm
The alarm words, warning words and extended status words
can be read out via serial bus or optional fieldbus for
diagnosis. See also 16-90 Alarm Word, 16-92 Warning Word
and 16-94 Ext. Status Word.
VLT HVAC Basic Drive Programming Guide
Warning
X
X
X
X
X
X
X
X
X
yellow
flashing red
®
MG.18.B1.02 - VLT is a registered Danfoss trademark
Alarm Trip Lock
X
X
X
X
X
X
X
X X
X
X
X
X X
X X
