Danfoss VLT HVAC Basic Drive Programming Manual page 52

Parameters
13-01 Start Event
Option: Function:
[25] Comparator 3 Use the result of comparator 3 in the
logic rule.
[26] Logic rule 0 Use the result of logic rule 0 in the logic
rule.
[27] Logic rule 1 Use the result of logic rule 1 in the logic
rule.
[28] Logic rule 2 Use the result of logic rule 2 in the logic
rule.
[29] Logic rule 3 Use the result of logic rule 3 in the logic
rule.
[33] Digital input DI18 Use the value of DI18 in the logic rule
(High = TRUE).
[34] Digital input DI19 Use the value of DI19 in the logic rule
(High = TRUE).
[35] Digital input DI27 Use the value of DI27 in the logic rule
(High = TRUE).
[36] Digital input DI29 Use the value of DI29 in the logic rule
(High = TRUE).
[39] Start command This event is TRUE if the frequency
*
converter is started by any means (either
via digital input, field bus or other).
[40] Drive stopped This event is TRUE if the frequency
converter is stopped or coasted by any
means (either via digital input, fieldbus
or other).
[42] Auto reset trip This event is TRUE if the frequency
converter is tripped (but not trip-locked)
and an Automatic Reset is issued.
[50] Comparator 4 Use the result of comparator 4 in the
logic rule.
[51] Comparator 5 Use the result of comparator 5 in the
logic rule.
[60] Logic rule 4 Use the result of logic rule 4 in the logic
rule.
[61] Logic rule 5 Use the result of logic rule 5 in the logic
rule.
[83] Broken belt A broken belt condition has been
detected. This function must be enabled
in 22-60 Broken Belt Function.
13-02 Stop Event
Option: Function:
Select the condition (TRUE or FALSE)
which will deactivate the Smart Logic
Controller.
[0] False Enters the fixed value of FALSE in the
logic rule.
VLT HVAC Basic Drive Programming Guide
13-02 Stop Event
Option:
[1]
[2]
[3]
[4]
[7]
[8]
[9]
[16] Thermal warning
[17] Mains out of range See 13-01 Start Event for further
[18] Reversing
[19] Warning
[20] Alarm (trip)
[21] Alarm (trip lock)
[22] Comparator 0
[23] Comparator 1
[24] Comparator 2
[25] Comparator 3
[26] Logic rule 0
[27] Logic rule 1
[28] Logic rule 2
[29] Logic rule 3
[30] SL Time-out 0
[31] SL Time-out 1
[32] SL Time-out 2
®
MG.18.B1.02 - VLT is a registered Danfoss trademark
Function:
True Enters the fixed value TRUE in the logic
rule.
Running See 13-01 Start Event for further
description.
In range See 13-01 Start Event for further
description.
On reference See 13-01 Start Event for further
description.
Out of current See 13-01 Start Event for further
range description.
Below I low See 13-01 Start Event for further
description.
Above I high See 13-01 Start Event for further
description.
See 13-01 Start Event for further
description.
description.
See 13-01 Start Event for further
description.
See 13-01 Start Event for further
description.
See 13-01 Start Event for further
description.
See 13-01 Start Event for further
description.
Use the result of comparator 0 in the
logic rule.
Use the result of comparator 1 in the
logic rule.
Use the result of comparator 2 in the
logic rule.
Use the result of comparator 3 in the
logic rule.
Use the result of logic rule 0 in the logic
rule.
Use the result of logic rule 1 in the logic
rule.
Use the result of logic rule 2 in the logic
rule.
Use the result of logic rule 3 in the logic
rule.
Use the result of timer 0 in the logic rule.
Use the result of timer 1 in the logic rule.
Use the result of timer 2 in the logic rule.
3 3
