Parameters

3.14.3 20-9* PI Controller

20-91 PI Anti Windup
Option: Function:
Select Off [0] to continue regulation of an error even
3 3
when the output frequency cannot be increased or
decreased. Select On [1] to cease regulation of an error
when the output frequency can no longer be adjusted.
[0] Off
[1] On
*
20-93 PI Proportional Gain
Range:
0.01 [0.0 - 10.0 ] Enter the process controller proportional
*
20-94 PI Integral Time
Range:
9999.0 s [0.1 - 9999.0
*
s]
20-97 PI Feed Forward Factor
Range:
0.0 %
*
68
VLT HVAC Basic Drive Programming Guide
Function:
gain. Quick control is obtained at high
amplification. However if amplification is too
great, the process may become unstable.
Function:
Enter the process controller integral time.
Obtain quick control through a short
integral time, though if the integral time
is too short, the process becomes
unstable. An excessively long integral
time disables the integral action.
Function:
[0.0 - 400.0 %]
