Parameters
13-40 Logic Rule Boolean 1
Array [6]
Option:
[23] Comparator 1
3 3
[24] Comparator 2
[25] Comparator 3
[26] Logic rule 0
[27] Logic rule 1
[28] Logic rule 2
[29] Logic rule 3
[30] SL Time-out 0
[31] SL Time-out 1
[32] SL Time-out 2
[33] Digital input DI18
[34] Digital input DI19
[35] Digital input DI27
[36] Digital input DI29
[39] Start command
[40] Drive stopped
[42] Auto reset trip
[50] Comparator 4
[51] Comparator 5
[60] Logic rule 4
[61] Logic rule 5
54
VLT HVAC Basic Drive Programming Guide
Function:
Use the result of comparator 1 in the
logic rule.
Use the result of comparator 2 in the
logic rule.
Use the result of comparator 3 in the
logic rule.
Use the result of logic rule 0 in the logic
rule.
Use the result of logic rule 1 in the logic
rule.
Use the result of logic rule 2 in the logic
rule.
Use the result of logic rule 3 in the logic
rule.
Use the result of timer 0 in the logic
rule.
Use the result of timer 1 in the logic
rule.
Use the result of timer 2 in the logic
rule.
Use the value of DI18 in the logic rule
(High = TRUE).
Use the value of DI19 in the logic rule
(High = TRUE).
Use the value of DI27 in the logic rule
(High = TRUE).
Use the value of DI29 in the logic rule
(High = TRUE).
This logic rule is TRUE if the frequency
converter is started by any means
(either via digital input, or other).
This logic rule is TRUE if the frequency
converter is stopped or coasted by any
means (either via digital input, or other).
This logic rule is TRUE if the frequency
converter is tripped (but not trip-
locked) and an Automatic Reset is
issued.
Use the result of comparator 4 in the
logic rule.
Use the result of comparator 5 in the
logic rule.
Use the result of logic rule 4 in the logic
rule.
Use the result of logic rule 5 in the logic
rule.
MG.18.B1.02 - VLT
13-40 Logic Rule Boolean 1
Array [6]
Option:
[70] SL Time-out 3
[71] SL Time-out 4
[72] SL Time-out 5
[73] SL Time-out 6
[74] SL Time-out 7
[83] Broken belt
[100] Firemode
13-41 Logic Rule Operator 1
Option:
[0] Disabled
*
[1] AND
[2] OR
[3] AND NOT
[4] OR NOT
[5] NOT AND
[6] NOT OR
[7] NOT AND NOT
[8] NOT OR NOT
13-42 Logic Rule Boolean 2
Array [6]
Option:
[0] False
*
[1] True
[2] Running
[3] In range
[4] On reference
[7] Out of current range
[8] Below I low
[9] Above I high
[16] Thermal warning
[17] Mains out of range
®
is a registered Danfoss trademark
Function:
Use the result of timer 3 in the logic
rule.
Use the result of timer 4 in the logic
rule.
Use the result of timer 5 in the logic
rule.
Use the result of timer 6 in the logic
rule.
Use the result of timer 7 in the logic
rule.
A broken belt condition has been
detected. This function must be
enabled in 22-60 Broken Belt Function.
The frequency converter is operating in
fire mode. See parameter group 24-0*
Fire Mode
Function:
Function:
Select the second boolean (TRUE or
FALSE) input for the selected logic
rule.
See 13-40 Logic Rule Boolean 1 for
further descriptions of choices and
their functions.
