Parameters

3.7.5 6-9* Analog/Digital Output 42

Parameters for configuring the limits for analog/digital
output Terminal 42. Analog outputs are current outputs: 0/4
- 20mA. Resolution on analog outputs is 12 bit. Analog
3 3 output terminals can also be setup as digital output.
6-90 Terminal 42 Mode
Option:
[0] 0-20 mA
*
[1] 4-20 mA
[2] Digital Output
6-91 Terminal 42 Analog Output
Option:
[0] No operation
*
[100] Output frequency 0 - 100Hz
[101] Reference
[102] Feedback
[103] Motor current
[106] Power
[139] Bus Control
6-92 Terminal 42 Digital Output
Option:
[0] No operation
*
[1] Control ready
[2] Drive ready
[3] Drive ready/remote control
[4] Standby / no warning
[5] VLT running
[6] Running / no warning
[7] Run in range/no warning
[8] Run on ref/no warning
[9] Alarm
[10] Alarm or warning
[12] Out of current range
[13] Below current, low
[14] Above current, high
[21] Thermal warning
44
VLT HVAC Basic Drive Programming Guide
Function:
Set Terminal 42 to act as analog output or as
digital output.
Function:
Select the function of Terminal 42 as an
analog current output. See also
6-90 Terminal 42 Mode.
MinRef. - MaxRef.
MinFB - MaxFB
0 - I
max
0 - P
nom
0 - 100%
Function:
Select the function of
Terminal 42 as an
analog current output.
See also 6-90 Terminal
42 Mode. See
5-40 Function Relay for
description of the
choices.
MG.18.B1.02 - VLT
6-92 Terminal 42 Digital Output
Option:
[22] Ready, no thermal warning
[23] Remote, ready, no thermal warning
[24] Ready, Voltage OK
[25] Reverse
[26] Bus OK
[35] External Interlock
[36] Control word bit 11
[45] Bus Control
[60] Comparator 0
[61] Comparator 1
[62] Comparator 2
[63] Comparator 3
[64] Comparator 4
[65] Comparator 5
[70] Logic rule 0
[71] Logic rule 1
[72] Logic rule 2
[73] Logic rule 3
[74] Logic rule 4
[75] Logic rule 5
[80] SL digital output A
[81] SL digital output B
[82] SL digital output C
[83] SL digital output D
[160] No alarm
[161] Running reverse
[165] Local ref. active
[166] Remote ref. active
[167] Start command activ
[168] Drive in hand mode
[169] Drive in auto mode
[193] Sleep Mode
[194] Broken Belt Function
[196] Fire Mode
[198] Drive Bypass
6-93 Terminal 42 Output Min Scale
Range:
0.0 % [0.0 - 200.0
*
%]
®
is a registered Danfoss trademark
Function:
Function:
Scale for the minimum output (0 or 4mA) of
the analogue signal at Terminal 42. Set the
value to be the percentage of the full range
of the variable selected in 6-91 Terminal 42
Analog Output.
