2.6.3 M&C Terminal Setup
You can do the initial field checkout of the modem in Terminal Mode. The Terminal Mode gives
you full screen access to the modem's parameters. However, it requires a separate terminal or
computer running a terminal program such as Hyper-terminal, and connection to the applicable
pins on the Remote Port connector (J3).
You can change these settings via the Web Browser.
Emulation Type:
Baud Rate:
Data Bits:
Parity:
2.6.3.1 Web Browser and Terminal Interfaces Reset
If you cannot use the Web Browser or Terminal interface, reset the interface defaults.
To reset the interface defaults, use the shorting plug (CNRSHUNT). Do these steps:
1. Make sure the electrical power to the unit is disconnected.
2. Find the JP1 and JP2 connectors.
3. Find pins 1 and 2 on the JP1 and JP2 connectors.
4. Install the CNRSHUNT shorting plug on pins 1 and 2 of JP1, and pins 1 and 2 of JP2.
5. Connect the electrical power to the unit.
This resets the interface defaults. See Section 3 for more information.
2.7

Storage

Store the unit in its original packaging. Store the unit in a dry location, where the temperature is
stable. Keep it away from direct contact with rain, snow, wind, sun or anything that may cause
damage to it.
Installation
Recommended Terminal Settings
VT-100
19.2 K
8
No Parity (Fixed)
2–6
