Comtech EF Data DMD1050TS Installation And Operation Manual page 172

Monitor | ETH Link Status Page
JS2 Port
JS3 Port
JS4 Port
WAN Status
Web Browser
Down
•
Unresolved
•
10 Mbps Half
•
10 Mbps Full
•
100 Mbps Half
•
100 Mbps Full
•
Unused
•
Down
•
Unresolved
•
10 Mbps Half
•
10 Mbps Full
•
100 Mbps Half
•
100 Mbps Full
•
Unused
•
Down
•
Unresolved
•
10 Mbps Half
•
10 Mbps Full
•
100 Mbps Half
•
100 Mbps Full
•
Unused
•
7–50
DMD1050TS Satellite Modem Board
Read only; this shows the status of the LAN Port 1.
Down - the link is down.
•
Unresolved – cannot agree on connection speed.
•
10 Mbps Half – connected at 10 Base-T Half Duplex.
•
10 Mbps Full – connected at 10 Base-T Full Duplex.
•
100 Mbps Half – connected at 100 Base-T Half
•
Duplex.
100 Mbps Full – connected at 100 Base-T Full Duplex.
•
Unused – the port is not available.
•
Read only; this shows the status of the LAN Port 2.
Down - the link is down.
•
Unresolved – cannot agree on connection speed.
•
10 Mbps Half – connected at 10 Base-T Half Duplex.
•
10 Mbps Full – connected at 10 Base-T Full Duplex.
•
100 Mbps Half – connected at 100 Base-T Half
•
Duplex.
100 Mbps Full – connected at 100 Base-T Full Duplex.
•
Unused – the port is not available.
•
Read only; this shows the status of the FIPS Module Port.
Down - the link is down.
•
Unresolved – cannot agree on connection speed.
•
10 Mbps Half – connected at 10 Base-T Half Duplex.
•
10 Mbps Full – connected at 10 Base-T Full Duplex.
•
100 Mbps Half – connected at 100 Base-T Half
•
Duplex.
100 Mbps Full – connected at 100 Base-T Full Duplex.
•
Unused – the port is not available.
•
Read only; this shows the status of the WAN Port.
Revision 1
MN-DMD1050TS
