F.5

High Speed Mesh Applications

As shown in Figure F-4, the unique daisy chain capability of the EEI also lends itself to mesh
networks. You can add more nodes to the mesh system without additional router blades or
disruption of the existing traffic.
52 Mbps >
< 156 Mbps
LAN 1 Router
104 Mbps
52 Mbps
52 Mbps >
< 156 Mbps
LAN 2 Router
104 Mbps
52 Mbps
Appendix F
DMD 50
DMD 50
DMD 50
DMD 50
DMD 50
DMD 50
Figure 4 – High Speed Mesh
Figure F-4. High Speed Mesh
F–4
DMD1050TS Satellite Modem Board
< 52 Mbps
156 Mbps >
Router
DMD 50
104 Mbps
DMD 50
52 Mbps
DMD 50
< 52 Mbps
156 Mbps >
Router
DMD 50
104 Mbps
DMD 50
52 Mbps
DMD 50
MN-DMD1050TS
Revision 1
LAN 3
LAN 4
