6.9.5 BER Performance (16QAM Viterbi)

1E-1
1E-2
1E-3
1E-4
1E-5
1E-6
1E-7
1E-8
1E-9
0 1
Note: Eb/No values include the effect of using differential decoding and v.35 descrambling.
Technical Specifications
Typical
Performance
2 3 4 5 6

Figure 6-5. 16QAM BER Performance (Viterbi)

6–13
DMD1050TS Satellite Modem Board
16QAM Uncoded Theory
Specification
3/4 Rate
Specification
7/8 Rate
7 8 9 10 11
Eb/No in dB
