Transmit | AUPC Page
Tracking Rate
Local CL Action
Remote CL Action
Target EsNo (dB)
Range EsNo (dB)
REMOTE
Mode
Loopback
TX 2047 Pattern
Web Browser
0.5 to 6.0
•
HOLD
•
NOMINAL
•
MAXIMUM
•
HOLD
•
NOMINAL
•
MAXIMUM
•
1.0 to 25 dB
•
0 to 2.0 dB
•
The REMOTE page section contains the remote configuration parameters for the AUPC
function. Remote AUPC menus are available only when the modem is configured for
EFDATA mode.
DISABLE
•
NEAR SIDE
•
EFDATA
•
ENABLE (option)
•
DISABLED
•
ENABLED
•
DISABLED
•
ENABLED
•
7–27
DMD1050TS Satellite Modem Board
Read only.
Set the rate at which the commands to increase or
decrease Transmit Power are sent. Each command will
result in a 0.5 dB increase or decrease in Transmit Power
from the remote transmitter. The tracking rate is adjustable
from 0.5 dB per minute to 6.0 dB per minute in 0.5 dB
steps. (Only available when EFAUPC is selected as the
framing)
Read only.
Set the remote transmit power setting used when the local
modem receiver loses lock. The setting can be HOLD (no
action taken), NOMINAL (the nominal transmit power
setting is used), or MAXIMUM (the maximum transmit
power setting is used). (Only available when EFAUPC is
selected as the framing)
Read only.
Set the local transmit power setting used when the remote
modem receiver loses lock. The setting can be HOLD (no
action taken), NOMINAL (the nominal transmit power
setting is used), and MAXIMUM (the maximum transmit
power setting is used).
Read only.
Set the desired Eb/No for the local receiver.
EBEM AUPC: When configured for EBEM AUPC, this
setting is compared against the remote Eb/No and
commands to the local modem to increase or decrease the
local transmit power.
Defines the range the remote can drift above and below the
target Es/No before the local modem makes a power
adjustment. Only available in EBEM AUPC Mode.
Enable or disable the AUPC Function of the remote
modem.
The remote AUPC Function is the response of the local
modem to commands for an increase or decrease of the
Transmit Power in 0.5 dB steps and the command to
change to the setting indicated in the 'REMOTE CL
ACTION' Menu of the remote modem upon receiver loss of
lock.
Enable or disable the Baseband Loopback Test mode of
the remote modem.
Enable or disable the Transmit 2047 Pattern Test mode of
the remote modem.
