Slitter Asm - Duplo DocuCutter CC-229 Service And Parts Manual

Slitter Asm (Fig. 19)
NO P/N
1 881-801-000A
881-801-010A
2 881-803-000A
881-802-000A
3 881-805-000A
4 881-804-010A
881-804-020A
5 881-807-000A
881-807-010A
881-807-020A
881-807-030A
6 881-808-000A
7 881-827-000A
8 881-810-000A
9 881-115-000A
10 881-809-020A
11 881-806-000A
12 00B-00F-6901
13 00E-M10-E000
14 00G-M10-3112
15 881-812-000A
881-812-000A
881-812-010A
881-812-020A
881-812-030A
16 881-114-000A
881-114-010A
881-114-020A
881-114-030A
00E-M03-E000
17 881-113-000A
881-113-010A
00E-M03-E000
18 881-R17-000A
Name
Chassis, Slitter, 2 x 3.5"
Chassis, Slitter, 5.47X 4.21"
Side Plate, L, Slitter
Side Plate, R, Slitter
Shaft, Slitter, Lower
Shaft, Slitter, Upper, 2x3.5" Slitter
Shaft, Slitter, Upper, 5.47x4.21" Slitter
Slitting Wheel, Center Gutter, 0.5"
Slitting Wheel, Center Gutter, 6mm
Slitting Wheel, Center Gutter, 0.25"
Slitting Wheel, Center Gutter, 3mm
Slitting Wheel, Side Trim
O Ring, JASO 2027
Roller, Ejection Driving, Slitter
Belt, Transport, Slitter
Roller, Transport, Slitter
Slitting Wheel, Upper, CC-228
Ball Bearing, F6901ZZ
E-Ring, 10mm
Gear, M1.0, 31T, ID12
Deflector, Side Waste, 0.5"
Deflector, Center Gutter, 0.5"
Deflector, Center Gutter, 0.25"
Deflector, Center Gutter, 6mm
Deflector, Center Gutter, 3mm
Asm, Upper Ejection Roller
Roller, Upper, Ejection
Spring, Upper Ejection Roller
Pin, Upper Ejection Roller
E-Ring, M3
Roller, Lower, Ejection
Pin, Lower Ejection Roller
E-Ring, M3
Handle
- 49 -
Q'TY
1
1
1
1
1
1
1
1
1
1
1
2
PU
3
POM
2
PU
2
4
4
4
2
2
2
1
1
1
1
2
POM
2
2
2
4
POM
2
2
4
1
