Feed Tray Asm - Duplo DocuCutter CC-229 Service And Parts Manual

883-050-000A

Feed Tray Asm

NO P/N
1 881-211-000B
2 881-E02-000A
3 881-E03-000A
4 00S-000-5901
5 881-105-000B
881-215-000A
6
881-406-000A
7
881-217-000A
8
881-212-000B
9
883-050-100A
10
882-101-182A
883-070-060A
00S-00E-ESB5
00W-883-2463
2PH-716-102F
00C-000-1210
11
881-E12-000A
12
881-E13-000A
13
881-104-0000
14
881-E15-000A
15
881-E16-000A
16
00C-000-1205
17
881-E18-000A
18
881-E19-000A
19
881-E20-000A
20
881-E21-000A
21
881-E22-000A
22
881-403-000B
23
881-403-000C
24
881-403-000D
25
881-103-000B
26
00S-000-5902
27
(Fig. 5)
Name
Tray, Feed, CC-228
Shaft, Side Guide Sliding
Bracket, Side Guide Mounting
Standoff, 6.35 x 2.2mm
Side Guide, Feeder, CC-228
Thumb Screw, Feeder Side Guide
Shaft, Pivot, Feed Tray
Bracket, Feed Tray Mounting
Index, Center Alignment
Asm, Feed Tray Sensor, CC-229
Bracket, Paper Sensor Mounting
Asm, Paper Sensor
Sensor, EE-SB5
Wire, 63cm, 24 AWG
Housing, Female, 2-pin
Collar, OD16, ID10
Nylon Graphite Gasket, OD16, ID10.1
Nut, Center Alignment
Knob, Center Alignment
Nylon Graphite Gasket, OD21, ID10.2
Bushing, Ø10.1 x 2.5
Collar, OD16, ID8(00C-000-1205)
Plate, Pressure Scale
Lever, Pressure Adjustment
Plate, spring Force Adjustment
Bushing, OD12, ID7.5
Plate, Spring
Spring, Feed Tray Tension, Outer
Spring, Feed Tray Tension, Inner
Spring, Lever Tension
Plate, Feed Tray Extension
Standoff, 6.35 x 4(00S-000-5902)
- 31 -
Q'TY
1
1
2
4
2
2
1
2
1
1
1
1
1
1
1
Nylon
1
1
1
Nylon
1
POM
2
1
1
1
1
1
1
1
1
1
1
2
