Feed Roller Asm - Duplo DocuCutter CC-229 Service And Parts Manual

Feed Roller Asm (Fig. 7)
NO P/N
1 881-N01-000A
2 00B-0UF-L001
3 00R-000-1502
881-N03-000A
00R-010-520A
4 881-N04-000A
5 162-107-0400
6 00B-000-6201
7 881-N07-000A
8 881-N12-000A
9 881-N08-000A
10 00A-51G-FC12
02P-51G-180A
00O-000-FC12
11 00B-000-1209
Fig. 7
Name
Shaft, Feed Roller
Pillow Block Ball Bearings, UFL-001
Feed Roller, CC-228
Core, Feed Roller
Feed Roller
Shaft, Feed Driving
Bushing, OD7, ID6(162-107-0400)
Ball Bearing, 6201ZZ
Housing, Ball Bearing 6201ZZ
Bushing, OD16, ID12.1
Gasket
Asm, Pulley/Clutch, 51G/FC12
Pulley, 0.2 P,51G,ID18
One Way Clutch, OD18, ID12, FC-12
Hardening Bushing, OD12, ID9(LRT-91216)
- 35 -
Q'TY
1
1
3
1
1 PU
1
4
1
1
1
Nylon
1
1
1
1
1
