Middle Lower Trasport Roller Asm (Fig. 9)
NO P/N
1 881-H01-000A
2 00G-M10-1910
3 00B-00F-1980
4 00C-000-1205
5 02P-51G-08WK
6 00B-MXL-099C
7 00E-M08-000E
8 00B-MXL-132C
Fig. 9
Roller, Transport, CC-228
Gear, M1, 19T, ID 10
Ball Bearing, LF-1980ZZ
Collar, OD16, ID 8
Pulley, 0.2 P,51G, ID 8-WK
Belt, 0.2P, 99MXL, 8mm
E-Ring, 8mm
Belt, 0.2P, 132MXL, 8mm
