881-Q00-000A Upper Knife Driving Asm (Fig. 15)
NO P/N
1 881-704-000A
2 881-P02-000A
3 881-719-000A
4 881-701-000A
5 881-P05-000A
6 00B-00F-1910
7 881-721-000A
881-P07-010A
881-P07-020A
8 881-720-000A
881-P08-010A
881-P07-020A
9 881-722-000A
10 00E-M10-000E
00C-000-1201
11
12 00B-00R-1560
13 00B-000-1101
Name
Knife, Upper. CC-228
Plate, Upper K M
NIFE OUNTING
Link
Bushing, OD7.9, ID6.1
Shaft, Knife Driving
Ball Bearing, LF-1910zz
Arm, R, Knife Driving
Plate, Knife Driving
Block, Arm Link
Arm, L, Knife Driving
Plate, Knife Driving
Block, Arm Link
Shutter, Index, CC-228
E-Ring, 10mm
Collar, OD16, ID10
Ball Bearing, R-1560ZZ
Anti-Static Brush 3"
- 44 -
Q'TY
1
2
2
2
1
2
1
1
1
1
1
1
1
1
1
2
2
