Recommended Spare Parts List - Duplo DocuCutter CC-229 Service And Parts Manual

Recommended Spare Parts List

Part Number
00A-51G-FC12 Asm, Pulley/Clutch, 51G/FC12
Hardening Bushing, OD12, ID9(LRT-91216)
00B-000-1209
00B-0UF-L001 Pillow Block Ball Bearings, UFL-001
00B-MXL-099C Belt, 0.2P, 99 MXL, 8mm
00B-MXL-132C Belt, 0.2P, 132MXL, 8mm
00D-000-0304 Display, LCD, 4 Row x 20
00M-000-0401 Motor, CKM245-01AH
00M-000-0427 Motor, 103H7823-1760
00S-000-1604 Separator, CC-228
00S-000-5611 Spring, Rocker Tension, Outer {Folder Black}
00S-000-6105
Switch, Interlock,
02P-17G-0500 Pulley, 0.2 P, 17G, ID 5
02P-17G-0800 Pulley, 0.2 P, 17G, ID 8
02P-51G-080A Pulley, 0.2 P,51G, ID 8
02P-51G-08WK Pulley, 0.2 P,51G, ID8-WK
881-403-000B Spring, Feed Tray Tension, Outer
881-403-000C Spring, Feed Tray Tension, Inner
881-403-000D Spring, Lever Tension
881-405-070A Spring, Rocker Tension, Inner
881-704-000A Knife, Upper. CC-228
881-705-000A Knife, Lower, CC-228
881-714-000A Asm,
881-715-000A Asm, Left, Upper Knife Holding Spring
881-716-000A Asm, Right, Upper Knife Holding Spring
881-H01-000A Roller, Transport, CC-228
Roller, Upper, Transport
881-L01-000B
881-M01-000B Roller, Transport
883-010-260A Case, R, CC-229
883-020-050A Main Board
883-020-051A Adaptor Board, Firmware Upgrade
883-020-160A Asm, Cutting Knife Home Position Sensor
883-020-200A Asm, Die Home Position Sensor
883-020-250A
Asm, PCB, Control Panel
883-020-270A Key Pad, CC-229
883-020-280A Case, L, CC-229
Name
Middle, Upper Knife Holding Spring
- 54 -
