Lower Knife Asm - Duplo DocuCutter CC-229 Service And Parts Manual

881-P00-000A Lower Knife Asm (Fig. 16)
NO P/N
1 881-711-000A
2 881-705-000A
3 881-714-000A
881-714-010A
881-714-020A
881-714-030A
00B-000-L940
00E-M04-000E
4 881-717-000A
5 881-715-000A
881-715-010A
881-716-020A
881-716-030A
00B-000-L940
00E-M04-000E
6 881-716-000A
881-716-010A
881-716-020A
881-717-030A
00B-000-L940
00E-M04-000E
7 881-718-000A
8 Not in use
9 883-070-060A
00S-00E-ESB5
00W-883-2463
2PH-716-102F
Fig. 16
Name
Chassis, Cutting Knife Mounting CC-229
Knife, Lower, CC-228
Asm, Middle, Upper Knife Holding Spring
Spring, Middle, Upper Knife Holding Spring
Pin, Middle, Upper Knife Holding Spring
Bushing, Middle, Upper Knife Holding Spring
Ball Bearing, L940ZZ
E-Ring, 4mm
Nut, Middle, Upper Knife Holding Spring
Asm, Left, Upper Knife Holding Spring
Spring, Left, Upper Knife Holding Spring Asm
Pin, R/L, Upper Knife Holding Spring Asm
Bushing, R/L, Upper Knife Holding Spring Asm
Ball Bearing, L940ZZ
E-Ring, 4mm
Asm, Right, Upper Knife Holding Spring
Spring, Right, Upper Knife Holding Spring
Pin, R/L, Upper Knife Holding Spring
Bushing, R/L, Upper Knife Holding Spring
Ball Bearing, L940ZZ
E-Ring, 4mm
Nut, L/R Upper Knife Holding Spring Asm
Asm, Paper Sensor
Sensor, EE-SB5
Wire, 63cm, 24 AWG
Housing, Female, 2-pin
- 45 -
Q'TY
1
1
1
1
1
1
2
2
1
1
1
1
1
2
2
1
1
1
1
2
2
2
1
1
1
1
