883-070-000A Feed Ramp Asm - Duplo DocuCutter CC-229 Service And Parts Manual

883-070-000A Feed Ramp Asm

NO P/N
1 881-116-000A
881-F01-010A
881-F01-020A
2 00B-000-0905
3 881-F03-000A
881-F03-010A
881-F03-020A
881-F03-030A
881-F03-040A
881-F03-050A
881-F03-060A
00E-M04-000E
4 00S-000-1604
5 881-225-000A
6 883-070-060A
00S-00E-ESB5
00W-883-2463
2PH-716-102F
00S-881-0003
7
Name
Ramp, Feed
Plate, Ramp, Feed
Paper Registration
Angle Bracket
Asm, Separator
Base, Separator Asm
Lower Limit Plate, Separator
Pin, Separator Compression Spring Holding
Shaft, Pivot, Separator Holding Plate
Holder, Separator
Shaft, Pivot, Separator Holder
E-Ring M4
Separator, CC-228
SEPERATOR MTG
SEPERATOR PAD
Guide, Feed Ramp
Asm, Paper Sensor
Sensor, EE-SB5
Wire, 63cm, 24 AWG
Housing, Female, 2-pin
Spacer, TXP PLATE 3MM
- 33 -
Q'TY
1
1
4
4
1
1
1
1
1
1
1
2
1
POM
1
PU
1
1
1
1
1
1
2
