Slitter Left/Right Adj Asm - Duplo DocuCutter CC-229 Service And Parts Manual

883-190-000A Slitter Left/Right Adj Asm (Fig. 18)
NO P/N
1 883-190-010A
2 883-190-020A
3 00B-00F-1260
4 00C-000-1606
5 883-190-050A
6 883-190-060A
883-190-060B
00S-M04-006S
7 883-190-070A
8 883-190-080A
9 883-190-090A
10 00E-M06-000E
Fig. 18
Name
Nut, Slitter Left/Right Adj
Screw, Driving, Slitter Left/Right Adj
Ball Bearing, LF-1260zz
Collar, OD16, ID 6
Block, Slitter Fine Tune Adjustment Holding
Ball Steel, Pressure Holding
Spring, Ball Screw Pressure Holding
Screw, Set, M4x6
Joint, Slitter Fine Tune
Clamp, Slitter Joint Locking
Knob, Slitter Left/Right Adj
E-Ring, 6mm
- 48 -
Q'TY
1
1
2
1
1
2
2
2
1
1
1
1
