883-020-000A Operating Side- Side Plate Asm (Fig. 3)
NO P/N
1 883-020-010A
2 00R-000-1101
3 00B-000-0905
4 881-B04-000A
5 883-020-050A
883-020-051A
6 00M-000-0401
7 02P-17G-0500
8 00B-MXL-132C
9 00M-000-0427
10 02P-17G-0800
11 00B-MXL-099C
12 883-010-090A
13 00B-000-1680
14 00S-000-5904
15 00N-000-0012
16 883-020-160A
00S-00E-ESV3
00W-883-2463
2PH-716-102F
17 883-010-130A
883-010-131A
883-010-132A
00S-M04-030R
18 881-405-070A
00S-000-5611
19 883-010-180A
20 883-020-200A
00S-RX6-75NW
00W-883-2463
2PH-716-102F
21 883-020-210A
22 883-020-220A
883-020-231A
23
Name
Side Plate, Left
Rubber Foot
Angle Bracket
Stopper
Main Board
Adaptor Board, Firmware Upgrade
Motor, CKM245-01AH
Pulley, 0.2 P, 17G, ID 5.00
Belt, 0.2P, 132MXL, 8mm
Motor, 103H7823-1760
Pulley, 0.2 P, 17G, ID 8
Belt, 0.2P, 99 MXL, 8mm
Idle Roller
Ball Bearing, L-1680ZZ
Standoff, Idler
Nut, D Cut
Asm, Cutting Knife Home Position Sensor
Sensor, Omron, EE-SV3
Wire, 24 AWG, 63cm
Housing, Female, 2-pin
Asm, Rocker Tension Adjustment
Block, Rocker Tension Adj
Holder, Rocker Tension Spring
Screw, M4x30, Round Head
Spring, Rocker Tension, Inner
Spring, Rocker Tension, Outer {Folder Black}
Stud, Die Module Bottom Margin
Asm, Die Home Position Sensor
Sensor, RIKO RX675-NW
Wire, 24AWG, 63cm
Housing, Female, 2-pin
Cover, RIKO RX675-NW
Bracket, L, Die Module Mounting
Asm, Interlock Switch, Top Cover
- 27 -
Q'TY
1
2 NBR
4
1
1
1
1
1
MAR
1
1
1
MAR
1
1
1
1
1
1
1
1
1
3
1
1
1
1
1
1
1
1
1
1
1
1
