Slitter Asm - Duplo DocuCutter CC-228 Service And Parts Manual

2.15 Slitter Asm (Fig. 14)
NO Index
1 881-801-000A
2.15.01
881-801-010A
2 881-803-000A
2.15.02
881-802-000A
3 2.15.03 881-805-000A
4 881-804-010A
2.15.04
881-804-020A
5 881-807-000A
2.15.05
881-807-010A
881-807-020A
881-807-030A
6 2.15.06 881-808-000A
7 2.15.07 881-827-000A
8 2.15.08 881-810-000A
9 2.15.09 881-115-0000
10 2.15.10 881-809-020A
11 2.15.11 881-806-000A
12 2.15.12 00B-F69-01ZZ
13 2.15.13 00E-M10-E000
14 2.15.14 00G-M10-3112 Gear, M1.0, 31T, ID12
15 2.15.15 881-812-000A
881-812-000A
881-812-010A
881-812-020A
881-812-030A
16 2.15.16 881-114-0000
2.15.16.01 881-114-010A
2.15.16.02 881-114-020A
2.15.16.03 881-114-030A
2.15.16.04 00E-M03-E000
17 2.15.17.01 881-113-000A
881-113-010A
2.15.17.02
2.15.17.03 00E-M03-E000
18 2.15.18 881-R17-000A
P/N
Chassis, Slitter, 2 x 3.5"
Chassis, Slitter, 5.47X 4.21"
Side Plate, L, Slitter
Side Plate, R, Slitter
Shaft, Slitter, Lower
Shaft, Slitter, Upper, 2x3.5" Slitter
Shaft, Slitter, Upper, 5.47x4.21" Slitter
Slitting Wheel, Center Gutter, 0.5"
Slitting Wheel, Center Gutter, 6mm
Slitting Wheel, Center Gutter, 0.25"
Slitting Wheel, Center Gutter, 3mm
Slitting Wheel, Side Trim
O Ring, JASO 2027
Roller, Ejection Driving, Slitting Module
Belt, Transport, Slitting Module
Roller, Transport, Slitting Module
Slitting Wheel, Upper, CC-228
Ball Bearing, F6901ZZ
E-Ring, 10mm
Deflector, Side Waste, 0.5"
Deflector, Center Gutter, 0.5"
Deflector, Center Gutter, 0.25"
Deflector, Center Gutter, 6mm
Deflector, Center Gutter, 3mm
Asm, Upper Ejection Roller
Roller, Upper, Ejection
Spring, Upper Ejection Roller
Pin, Upper Ejection Roller
E-Ring, M3
Roller, Lower, Ejection
Pin, Lower Ejection Roller
E-Ring, M3
Handle
Name
- 22 -
Q'TY
1
1
1
1
1
1
1
1
1
1
2
PU
3
POM
2
PU
2
4
4
4
2
2
2
1
1
1
1
2
POM
2
2
2
4
POM
2
2
4
1
