Feed Roller Asm - Duplo DocuCutter CC-228 Service And Parts Manual

2.12 Feed Roller Asm (Fig. 11)
NO Index
1 881-N01-000A
2.12.01
2 2.12.02 00B-0UF-L001
3 2.12.03 00R-000-1502
881-N03-000A
4 881-N04-000A
2.12.04
5 2.12.05 162-107-0400
6 2.12.06 00B-062-01ZZ
7 2.12.07 00H-062-010A
8 2.12.08 881-N08-000A
9 2.12.09 08P-24G-1800
10 2.12.10 00O-000-FC12
11 2.12.11 00B-000-1209
Fig. 11
P/N
Shaft, Feed Roller
Pillow Block Ball Bearings, UFL-001
Feed Roller, CC-228
Core, Feed Roller
Shaft, Feed Driving
Bushing, OD7, ID6
Ball Bearing, 6201ZZ
Housing, Ball Bearing 6201ZZ
Gasket
Pulley, 0.8 P,24G,ID18
One Way Clutch, OD18, ID12, FC-12
Hardening Bushing, OD12, ID9(LRT-91216)
Name
- 18 -
Q'TY
1
1
3 PU
1
4
1
1
Nylon
1
1
1
1
