mDb
auDit protocol
- Aud.1 Money in tubes
money in the coin tubes at that point in time
- Aud.2 Money to tubes
Money sent to coin mech tubes
- Aud 3 Money to the counter
Money sent to coin till
- Aud 4 Change return
Total amount of returned change
- Aud 5 Surplus
Money surplus. Amounts overpaid by the client, which
have not been returned (in the event that there is no
availability of money for the change)
- Aud 6 Tubes distribution
Value of the coins returned in the "tubes management"
function
- Aud 7 Tubes payment
Value of the coins cashed in the manual loading fun-
ction.
- Aud 8 Cash retails
Value of total sales made in cash (coins + bills)
- Aud 9 Collected bills
Value of collected bills
- Aud 10 Key reload
Amount of money loaded on a key
- Aud 11 Key retails
Amount of money cashed through key retails
- Aud 12 Manually dispensed money
Value of the coins dispensed manually through the
distribution button on the coin box.
© by N&W GLOBAL VENDING S.p.A.
p
riNt statistics
By connecting an RS232 serial printer with a baud rate
of 9600, 8 data bits, parity of None and 1 stop bit to the
serial connector on the button board, it's possible to print
all the statistics described in the paragraphs "display
general statistics" and "display relative statistics"; the
printout also shows the code of the machine, the date
and the software version.
Printing the statistics can be performed in a relative or
total mode.
To connect the printer follow these steps:
- press the printing confirmation key � and the confirma-
tion request "Confirm?" is displayed;
- connect the printer before confirming;
- by pressing the confirmation key � printing will start.
