Notes about

Programming

The electronic control unit of the machine controls the
use of many functions.
The programme of the machine contains a description of
all the foreseen functions, including those which, for the
specific configuration of the model (layout), are not used.
The machine is supplied together with:
- Selections layout, which contains the selections forese-
en for the specific model
- Flow chart of the programming menu.
Described below is a summary of the main functions
which are useful for managing the operation of the
machine, not necessarily in the order in which they are
displayed in the menu.
The software version can be updated using the appro-
priate systems (PC, Giga, UpKey, etc.)
The display messages which show the operation in
progress are steady-on, while any action requested of
the user flashes.
The status of the machine can be in three different mo-
des.
Depending on the status in which the machine is, the
buttons of the keyboard assume different functions.
N
ormal usEr
- Machine start-up (door closure) with the execution of
the foreseen checks.
- Operations that can be done with the door closed.
- Dispensing selection and messages to the user.
l
oaDEr mENu
- Detection of statistical data and execution of simple
checks on the operation and on the dispensed items.
t
EcHNical mENu
- Programming of the settings and performance of the
machine, divided into two levels:
© by N&W GLOBAL VENDING S.p.A.

OPERATION IN NORMAL USER STATUS

During the normal operation, the display shows the mes-
sage to the user and the invitation to select the drink.
When the drink is being dispensed, an animation is
shown which indicates the stage of preparation of the
drink.
I N P R E P A R A T I O N
In the event that an anomaly is detected by the control
system, an error message will be given, indicating the
type of problem:
Depending on the settings, the lighting of the keyboard
may be red
At the end of the dispensing phase, the display shows
the following message for a few seconds:
22
SELECT A
BEVERAGE
Out of service
"fault name"
READY DRINK
COLLECT
09-2013 4485-00
