Tektronix 2246 1Y Service Manual page 2

TEK SERVICE
MANUAL
n
' ^
-< ■
r~
'
The following servicing instructions
are for use by qualified service
personnel only. To avoid personal
injury, do not perform any servicing
unless you are qualified to do so.
Refer to the Safety Summary prior
to performing any service.
[
I
First Printing JUL 1988
Revised OCT 1991
r
WARNING
Please check for CHANGE INFORMATION
at the rear of this manual.
2246 1Y, 2R
and
2246 MOD A
PORTABLE
OSCILLOSCOPE
SERVICE
SNB700100 and ABOVE (2246 1Y,2R)
SN B100100 and ABOVE (2246 MOD A)
The 2246 2R Is a rackmount version of the 2246 1Y. This service
manual and the 2240F1R Instruction sheet (Tektronix part number
070-6332-00) are required to fully service the 2246 2R
oscilloscope.
i
|
Part No. 070-7062-00
Product Group 46
Ifektronix
C O M M ITTE D T O EXCELLENCE
