4B-5 Fuel / Water Hose Routing:

Water Hose Routing

1
3
2
7
1. Water return hose
2. Fuel cooler
3. Water hose (Fuel cooler to water return union)
5
4
6
4. Water hose (Union to fuel cooler)
5. Water hose protector
6. Water union
Z9J0114202002
I9J011420005-02
7. Water return union
