  • Page 1 ARCO ROJECTION 200L/300/400 EALITY ARCOI RAPHICS R9002890 - R9002900 R9002700 - R9002730 R9002910 - R9002940 ’ WNER ANUAL 10062002 R5976367/02...
  • Page 2 Product revision Software version: V1.20 (A) Barco nv Intelligent Displays Noordlaan 5, 8520 Kuurne Phone: +32 56.36.82.11 Fax: +32 56.35.86.51 E-mail: presentations.bid@barco.com Visit us at the web: www.barco.com Printed in Belgium...
  • Page 3 The period of guarantee begins on the date of transfer of risks, in the case of special systems and software on the date of commissioning, at latest 30 days after the transfer of risks. In the event of justified notice of compliant, Barco can repair the fault or provide a replacement at its own discretion within an appropriate period.
  • Page 5 Revision Sheet Barco nv Intelligent Displays Noordlaan 5, 8520 Kuurne Phone: +32 56.36.82.11, Fax: +32 56.35.86.51 E-mail: presentations.bid@barco.com, Web: www.barco.com From: Date: Please correct the following points in this documentation (R5976367/02): page wrong correct R5976367 B 200L/300/400 10062002 ARCOI RAPHICS...

  • Page 7: Table Of Contents

    Table of contents TABLE OF CONTENTS 1. Packaging and Dimensions ..................5 1.1 Box content.
  • Page 8 Table of contents 7. Image Menu ......................53 7.1 Overview .
  • Page 9 Table of contents Glossary ....................... 115 Index.
  • Page 10 Table of contents R5976367 BARCOIQ GRAPHICS/REALITY 200L/300/400 10062002...

  • Page 11: Packaging And Dimensions

    1. Packaging and Dimensions 1. PACKAGING AND DIMENSIONS Overview • Box content • Projector Packaging • Lens Packaging • Dimensions 1.1 Box content CEE7 European power plug to connect the power cord to the wall outlet. ANSI 73.11 American power plug to connect the power cord to the wall outlet. Content •...

  • Page 12: Lens Packaging

    1. Packaging and Dimensions Image 1-1 Image 1-2 Save the original shipping carton and packing material, they will be necessary if you ever have to ship your projector. For maximum protection, repack your projector as it was originally packed at the factory. Save the original shipping carton and packing material, they will be necessary if you ever have to ship your projector.
  • Page 13 1. Packaging and Dimensions Image 1-3 Lens length of projector combinable with cable Remarks basket SVD(2-2.5:1) 545mm Length with cable basket = 565mm R5976367 BARCOIQ GRAPHICS/REALITY 200L/300/400 10062002...
  • Page 14 1. Packaging and Dimensions Lens combinable with cable Remarks length of projector basket QVD(1.3-1.8:1) 600mm QVD(1.9-2.6:1) 590mm QVD(3.0-6.0:1) 620mm QVD(0.85:1) 545mm QVD(7.0:1) 540mm Length with cable basket = 560mm R5976367 BARCOIQ GRAPHICS/REALITY 200L/300/400 10062002...

  • Page 15: Installation Guidelines

    It is advised to clean the dustfilters on a regular basis and to replace them at any lamp change. Barco reserves itself the right to refuse warranty replacement of consumables if they have been used in a projector with dirty airfilters.

  • Page 16: Projector Configurations

    2. Installation Guidelines What about ambient light ? The ambient light level of any room is made up of direct or indirect sunlight and the light fixtures in the room. The amount of ambient light will determine how bright the image will appear. So, avoid direct light on the screen. Windows that face the screen should be covered by opaque drapery while the set is being viewed.
  • Page 17 2. Installation Guidelines Positioning the projector Image 2-2 ON-Axis installation side view top view back view optical axis projection lens projector screen floor R5976367 BARCOIQ GRAPHICS/REALITY 200L/300/400 10062002...
  • Page 18 2. Installation Guidelines Image 2-3 100% OFF Axis installation side view top view back view optical axis projection lens projector screen floor R5976367 BARCOIQ GRAPHICS/REALITY 200L/300/400 10062002...

  • Page 19: Lenses

    Lens installation • Removing the lens • Cleaning the lens 2.4.1 Lenses Available lenses The following lenses are available, or will become available (contact a BARCO service center) as an option : Lenses Standard version QVD(0.85:1) R9841220 QVD(1.3-1.8:1) R9840950 QVD(1.9-2.6:1) R9840960 QVD(3.0-6.0:1)

  • Page 20: Lens Installation

    2. Installation Guidelines 2.4.3 Lens installation How to install ? 1. Take the lens out of its packing material 2. Slide the lensdoor to the left (image 2-4) 3. Fix the lens by placing it in the housing Note: In case of a motorized lens the female jack must be in front of the male jack located in the upper-left part of the housing in the projector (image 2-5) 4.

  • Page 21: Cleaning The Lens

    2. Installation Guidelines 2.4.5 Cleaning the lens To minimize the possibility of damaging the optical coating or scratching exposed lens surface, we have de- veloped recommendations for cleaning the lens. FIRST, we recommend you try to remove any material from the lens by blowing it off with clean, dry deionized air.
  • Page 22 The common address can be zero (0) or one (1). The standard RCU are setup for common address zero. To change the common address of the RCU, contact a BARCO service center. If it is necessary to program the projector address into the RCU, see chapter ’Getting Started’.

  • Page 23: Connections

    3. Connections 3. CONNECTIONS Overview • Power connection • Input source connection • 5-Cable input • Composite Video Input • S-Video input • Digital Visual Interface (DVI) input • Computer input • Serial Digital Interface (Optional) • Audio input/Output (Optional) •...

  • Page 24: Input Section

    3. Connections 3.2.1 Input section Input Layers The input section is divided in layers, each of them regrouping several inputs, this architecture allows the input section to be upgraded at any time with an optional analog or digital layer. Layer 1: analog layer containing analog data and video inputs Layer 2: a hybrid layer containing 2 digital and 1 analog input Layer 3 : is an optional layer, it may be an Audio &...

  • Page 25: 5-Cable Input

    3. Connections Layer 3 can be an optional audio&video layer or an optional SDI (SDI Input/Output) (image 3-3) Image 3-3 source input section with optional SDI layer A cable cover is supplied with the projector and can be fitted on the front of the projector (image 3-4) Image 3-4 Cable basket : the white arrow shows the cables leaving the projector Front view...

  • Page 26: Composite Video Input

    3. Connections Image 3-5 Component Video In Component Video the term component describes a number of elements that are needed to make up the video picture, these components are PR/Y/PB. A composite video signal on the other had contains all the information needed for the color picture in a single channel of information Which signals can be connected ? Signals/Input BNC...

  • Page 27: S-Video Input

    3. Connections Image 3-6 How to select a Composite Video Input ? 1. Press 3 on the RCU Note: Another way for selecting this input is via Source on the local keypad or via the Menu. The projector allows the input of more composite video signals (up to 7 composite video signals). 5 cable extended configuration, page 25 The Audio&Video optional layer(3) allows the use of an additional Video BNC input (referred to as Video2).

  • Page 28: Digital Visual Interface (Dvi) Input

    3. Connections How to select the S-Video input ? 1. Press 4 on the RCU Note: Another way for selecting this input is via Source on the local keypad or via the Menu. The projector allows the input of more S-Video signals (up to 3 composite video signals). S-Video extended configuration, page 26 The Audio&Video optional layer(3) allows the use of an additional S-Video input (referred to as S-Video4).

  • Page 29: Serial Digital Interface (Optional)

    3. Connections Image 3-9 What can be connected ? • RGBHV • • Pr/Y/Pb Composite sync only possible on Green How to select a computer input ? 1. Press 2 on the RCU Note: Another way for selecting this input is via Source on the local keypad or via the Menu. 3.8 Serial Digital Interface (Optional) Serial Digital Interface Input specifications...

  • Page 30: Audio Input/Output (Optional)

    3. Connections How to select the SDI input 1. Press 7 on the RCU Note: Another way for selecting this input is via Source on the local keypad or via the Menu. The SDI is located on Layer3 which is an optional Layer. 3.9 Audio input/Output (Optional) Input specification Typical = 200 mV...

  • Page 31: Extended Configuration

    3. Connections Image 3-12 Applications of the RS232 connection Remote control: • easy adjustment of projector via IBM PC (or compatible) or MAC connection. • address range from 1 to 255 • allow storage of multiple projector configurations and set ups. •...

  • Page 32: Video Extended Configuration

    3. Connections Inputs VIDEO Signals RGBHV RGBS Component S-Video S-Video Composite VIDEO VIDEO Composite VIDEO Composite Composite VIDEO Composite VIDEO Table 3-2 Extended configuration of the 5 cable input: the first column gives the possible signals, and the first row the 5 cable input connectors (+ the standard Video BNC). How to set up the 5 cable extended configuration ? 1.

  • Page 33: 4Summarizing

    3. Connections How to set up the S-Video extended configuration ? 1. Connect the video sources to the desired connector (image 3-16) Note: An adapter cable is required Image 3-16 Connecting 2 composite Video signals on the S-Video connector Multiple video signals can not be visualized simultaneously since there is only one decoder. However, the use of the optional Audio &...
  • Page 34 3. Connections R5976367 BARCOIQ GRAPHICS/REALITY 200L/300/400 10062002...

  • Page 35: Getting Started

    4. Getting started 4. GETTING STARTED Overview • RCU & Local keypad • Terminology overview • Switching on • Lamp runtime • Quick set up adjustments • Projector address • Controlling the projector • Digital Zoom • Menu structure • Using the menu •...

  • Page 36: Terminology Overview

    4. Getting started Image 4-1 Local keypad layout Remote control functions. This remote control includes a battery powered infrared (IR) transmitter that allows the user to control the projector remotely. This remote control is used for source selection, control, adaptation and set up. It includes automatic storing of picture controls (Bright- ness, Sharpness...) and settings.
  • Page 37 4. Getting started Image 4-2 Function keys user programmable keys with functions for direct access. MENU Menu key, to enter or exit the Toolbar menu. Address key (recessed key), to enter the address of the projector (between 0 and 9). Press the recessed address key with a pencil, followed by pressing one digit button between 0 and 9.

  • Page 38: Switching On

    4. Getting started FREEZ press to freeze the projected image. allows to activate the PICTURE IN PICTURE mode ENTER to confirm an adjustment or selection in the MENU. On the local keypad the ENTER button additionally accesses the PIP window resize function Cursor keys Cursor Keys on RCU or on the local keypad : to make menu selections or to access the toolbar.
  • Page 39 This warning message will be repeated at the next start up. Press BACK or MENU to remove the message. The total lifetime of the lamp for a safe operation is “x” hours max, do not use it longer. Always replace with a same type of lamp. Call a BARCO authorized service technician for lamp replacement. BarcoIQ...

  • Page 40: Quick Set Up Adjustments

    Using a lamp for more than x hours is dangerous as the lamp could explode. The lamp runtime reset as well as the lamp replacement can only be done by a Barco authorized technician. 4.5 Quick set up adjustments...

  • Page 41: Using The Rcu

    4. Getting started Quick zoom/focus adjustment 1. Press LENS ZOOM or LENS FOCUS on the RCU 2. Use the arrow keys to adjust Quick shift adjustment 1. Press LENS SHIFT 2. Use the arrow keys to adjust 4.5.2 Using the RCU Pointing to a reflective screen 1.

  • Page 42: Projector Address

    4. Getting started Image 4-10 Stereo jack pin configuration tip: Left channel ring: right channel screen: common (GND) external switch How to connect ? 1. Plug one end of the remote cable in the connector on the bottom of the RCU. 2.

  • Page 43: Displaying And Programming Addresses Into The Rcu

    4. Getting started Set up an individual Projector Address. The set up of a projector address can be done via the software. . Projector controlling. Every projector requires an individual address between 0 and 255 which can be set in the Installation menu. When the address is set, the projector can be controlled now: •...

  • Page 44: Digital Zoom

    4. Getting started Color Use the + button for richer colors. Use the - button for lighter colors. Tint(Hue) Tint is only active for Video and S-Video when using the NTSC 4.43 or NTSC 3.58 system. Use the + button Use the - button.

  • Page 45: Using The Menu

    4. Getting started 4.10Using the menu Menu Layout A grey line gives the transition between standard and advanced parameters. The existence of a submenu is indicated by a white arrow, Mode is a submenu. Runtimes is an item of the Lamp menu. Three suspension points indicate that the menuitem hides a dialogbox or a textbox.
  • Page 46 4. Getting started Entering numeric values using the numeric keys on the remote control 1. Press ENTER to activate the input field (image 4-15) 2. Key in the desired value Image 4-15 Entering numeric values using the arrow keys on the remote control 1.

  • Page 47: Source Selection

    5. Source Selection 5. SOURCE SELECTION Overview • Flowchart • Source selection • Composite Video • S-Video selection • The Video Selector 5.1 Flowchart The source selection menu structure Image 5-1 flowchart of the Source selection menu R5976367 BARCOIQ GRAPHICS/REALITY 200L/300/400 10062002...

  • Page 48: Source Selection

    On the screen appears now the selected source. Image 5-2 The Barco logo on the menu indicates the presence of a signal, the digit indicates the shortcut key on the RCU. The 3 first sources (Data on BNC’s, Component Video & RG(s)B) refer to the 5-cable input, the position of the indication “1”...

  • Page 49: Composite Video

    5. Source Selection 5.3 Composite Video How to select one of the 7 composite video inputs ? 1. Press MENU to activate the Toolbar 2. Press ↓ to Pull down the Source Selection menu 3. Use ↑ or ↓ to select Composite video 4.

  • Page 50: The Video Selector

    5. Source Selection Image 5-4 The S-Video sources can also be selected using the video selector or via the dedicated key 4 on the RCU. Key 4 allows to browse through the active video inputs. 5.5 The Video Selector Video Selector The Video Selector is a graphical interface which allows an overview of the different video inputs (Composite Video and S-Video) and whether they are active (signal connected) or not as well as the selection of these different signals.
  • Page 51 5. Source Selection Image 5-7 Image 5-6 If the Audio/Video option is installed the Video Selector is updated with the additional Video & S-Video input (image 5-8) Image 5-8 R5976367 BARCOIQ GRAPHICS/REALITY 200L/300/400 10062002...
  • Page 52 5. Source Selection How to select an input on the Video Selector ? 1. Use ←or→ to browse through the different inputs 2. Press ENTER Use MENU or BACK to exit the Video Selector How to disable the extended Video Selector 1.

  • Page 53: General Menu

    6. General Menu 6. GENERAL MENU Overview • Flowchart • Pause • Freeze • Standby Timer • Audio (Optional) • Identification 6.1 Flowchart The General menu structure Image 6-1 6.2 Pause Interrupting the image projection With the Pause function, the image projection can be stopped, the projector remains with full power for immediate restart. The projection is interrupted by means of a mechanical shutter cutting the light beam.

  • Page 54: Freeze

    6. General Menu How to interrupt the image projection ? 1. Press MENU to activate the Toolbar 2. Press → to select General 3. Press ↓ to Pull down the General menu 4. Use ↑ or ↓ to select Pause (image 6-2) 5.

  • Page 55: Audio (Optional)

    6. General Menu Image 6-4 The countdown time can be set in a dialog box in a range from 180 to 3600 seconds (default value = 300). The Timer can also be disabled. How to enable the timer ? 1. Press MENU to activate the Toolbar 2.
  • Page 56 6. General Menu Image 6-7 Audio flow diagram Ax Audio inputs audio mute audio – image linking : one or more audio input(s) can be linked to one or more video or data source (1...15) audio multiplexer + mixer audio setting : volume, bass, treble, balance Audio output Starting the Audio Setup menu 1.

  • Page 57: Audio Settings

    6. General Menu How to mute an Audio channel ? 1. use the arrow keys to select the desired mute box 2. Press ENTER How to link an audio input to a source ? 1. use the arrows to select the desired scroll box 2.
  • Page 58 6. General Menu How to display the identification screen ? 1. Press MENU to activate the Toolbar 2. Press → to select General 3. Press ↓ to Pull down the General menu 4. Use ↑ or ↓ to select Identification (image 6-10) 5.

  • Page 59: Image Menu

    7. Image Menu 7. IMAGE MENU Overview • Overview • Settings • Aspect ratio • Show native resolution • Keystone • Color temperature • Filmmode detection • Input balance • AGC on Video • Manual Gain Control R5976367 BARCOIQ GRAPHICS/REALITY 200L/300/400 10062002...

  • Page 60: Overview

    7. Image Menu 7.1 Overview The Image menu structure Image 7-1 R5976367 BARCOIQ GRAPHICS/REALITY 200L/300/400 10062002...

  • Page 61: Settings

    7. Image Menu 7.2 Settings Overview • Contrast • Brightness • Color • Tint (hue) • Sharpness • Gamma • Phase • Noise reduction What can be done ? Correct image settings are important for a good image reproduction. The image settings are made through a dialogbox with a scrollbar, image 7-3.

  • Page 62: Brightness

    7. Image Menu 7.2.2 Brightness How to change the Brightness ? 1. Press MENU to activate the Toolbar 2. Press → to select the Image item 3. Press ↓ to Pull down the Image menu 4. Use ↑ or ↓ to select settings 5.

  • Page 63: Gamma

    7. Image Menu 7.2.6 Gamma How to change the Gamma 1. Press MENU to activate the Toolbar 2. Press → to select the Image item 3. Press ↓ to Pull down the Image menu 4. Use ↑ or ↓ to select settings 5.

  • Page 64: Show Native Resolution

    7. Image Menu Selecting Auto in case of a Video source may shrink the image horizontally How to change the Aspect ratio ? 1. Press MENU to activate the Toolbar 2. Press → to select Image 3. Press ↓ to Pull down the Image menu 4.

  • Page 65: Keystone

    7. Image Menu Image 7-4 The default mode is used if the show native resolution and the full screen function are off. The default mode shows always the native ratio and forces the native resolution of the panels (part of the image blanked where needed) 7.5 Keystone What can be done ?
  • Page 66 7. Image Menu These calibrated presets can be selected and will provide optimum color tracking, the projector allows however the setting of a personal color temperature, this is done in custom How to select a preset color temperature ? 1. Press MENU to activate the Toolbar 2.

  • Page 67: Filmmode Detection

    7. Image Menu Image 7-10 Image 7-11 7.7 Filmmode detection What can be done ? Some sources like common DVD material are derived from cinema 24 Hz sources (2/2 or 3/2 pull down method). The filmmode detection insures that these converted signals are shown without artefacts. This function may cause undesired effects on standard sources, therefore it can be disabled (OFF) at any time Enabling/disabling the filmmode detection 1.
  • Page 68 7. Image Menu • Black balance • White balance The default value (factory settings) of the input balance can be restored at any time. Before starting the Input Balance procedure, generate a grey scale signal with the same amplitude as the source.

  • Page 69: Agc On Video

    7. Image Menu Image 7-17 Selecting Preset restores the factory input balance setting Remark on the input balance of component video source Before starting the Input Balance procedure, generate a signal with dominant white parts. Input balance is also available for a component video source under following conditions: •...

  • Page 70: Manual Gain Control

    7. Image Menu AGC is only for Video signals Enabling/disabling the AGC 1. Press MENU to activate the Toolbar 2. Press → to select the Image item 3. Press ↓ to Pull down the Image menu 4. Use ↑ or ↓ to select AGC on Video 5.
  • Page 71 7. Image Menu Image 7-21 Image 7-22 R5976367 BARCOIQ GRAPHICS/REALITY 200L/300/400 10062002...
  • Page 72 7. Image Menu R5976367 BARCOIQ GRAPHICS/REALITY 200L/300/400 10062002...

  • Page 73: Tools Menu

    8. Tools Menu 8. TOOLS MENU Overview • Flowchart • Introduction to PiP • PiP select • PiP add window • PiP remove window • PiP layout • PiP Adjust • Diagnostics 8.1 Flowchart Overview of the Tools menu Image 8-1 R5976367 BARCOIQ GRAPHICS/REALITY 200L/300/400 10062002...

  • Page 74: Introduction To Pip

    8. Tools Menu 8.2 Introduction to PiP PiP stands for "Picture in Picture" and allows to display multiple windows containing each of them an image. It allows to display up to 4 different windows coming from 2 data and 2 video sources. What are the different possibilities within the PiP mode ? The input section of the IQ projector allows a multitude of combinations of different input signals which may be projected in the 4 windows of the PiP screen.

  • Page 75: Pip Select

    8. Tools Menu PiP dedicated buttons • PiP Adjust : this button allows to focus on one particular window, this is shown with a white frame surrounding the selected window. A source identification box is displayed in the right lower corner. Image 8-3 Pressing the button removes the frame to the next window.

  • Page 76: Pip Add Window

    8. Tools Menu 8.4 PiP add window What can be done ? It is possible to add a window to the existing windows (maximum 4), therefore a source must be selected. Sources which are already used are unselectable. If for instance the PiP layout contains a component video then component video will be unselectable.

  • Page 77: Pip Layout

    8. Tools Menu Image 8-7 Image 8-8 8.6 PiP layout Overview • PiP Save • PiP rename layout • PiP delete layout 8.6.1 PiP Save What can be done ? The active layout can be saved or "saved as". When a new layout is saved it is added to the PiP select menu. A fixed layout can be edited (resizing, repositioning,...) but it can not be saved under its original name.

  • Page 78: Pip Rename Layout

    8. Tools Menu Image 8-10 Image 8-11 8.6.2 PiP rename layout What can be done ? The non fixed layouts (factory and personal layouts) can be renamed . The maximal length of the name is 12 characters. A fixed layout can not be renamed How to rename a layout ? 1.

  • Page 79: Pip Delete Layout

    8. Tools Menu 8.6.3 PiP delete layout What can be done ? The non fixed layouts (factory and personal layouts) can be deleted. The fixed layouts and the active layout can not be deleted How to delete a layout ? 1.

  • Page 80: Diagnostics

    8. Tools Menu Image 8-17 PiP adjust in case of 2by2 layout Data1 window has the focus, new settings will only affect Data1 window Video1 window has the focus, new settings will only affect Video1 window PiP adjust 1. Press MENU to activate the Toolbar 2.
  • Page 81 8. Tools Menu Image 8-19 Image 8-20 R5976367 BARCOIQ GRAPHICS/REALITY 200L/300/400 10062002...
  • Page 82 8. Tools Menu R5976367 BARCOIQ GRAPHICS/REALITY 200L/300/400 10062002...

  • Page 83: Signal Menu

    9. Signal Menu 9. SIGNAL MENU Overview • Flowchart • Switching mode • Background 9.1 Flowchart The signal menu structure Image 9-1 9.2 Switching mode Switching from one source to another To minimize undesired effects when switching from one source to another, one can use the Seamless switching mode, beside Seam- less switching there is a wide choice of several effects which render the source switching transitions more enjoyable.
  • Page 84 9. Signal Menu How to select a switching mode ? 1. Press MENU to activate the Toolbar 2. Press → to select the Signal item 3. Press ↓ to Pull down the Signal menu 4. Use ↑ or ↓ to select Switching mode 5.

  • Page 85: Background

    9. Signal Menu Image 9-3 Video may be Composite video/ S-Video / SDI • dark arrow : fade in/out effect possible • dotted arrow : undetermined case, fade in/out effect may take place or not • striked out arrow : fade effect impossible The switching effects are only possible in the full screen mode When the source switching mode is the fade in/out mode, the audio switching will also be done using a fade in/out effect.
  • Page 86 9. Signal Menu How to change the background ? 1. Press MENU to activate the Toolbar 2. Press → to select the Signal item 3. Press ↓ to Pull down the Signal menu 4. Use ↑ or ↓ to select Background 5.

  • Page 87: Lamp Menu

    10. Lamp Menu 10. LAMP MENU Overview • Flowchart • Runtimes • Mode • History • Reset runtime • Runtime warning 10.1Flowchart Overview of the Lamp menu Image 10-1 10.2Runtimes How to display the lamp runtimes ? 1. Press MENU to activate the Toolbar 2.

  • Page 88: Mode

    10. Lamp Menu Image 10-2 Image 10-3 Runtime textbox: yellow indicator means the lamp is working 10.3Mode What are the different lamp modes ? Single mode The projector will always switch to the lamp with the shortest runtime when the difference between the runtimes of lamp1 and lamp 2 reaches 100 hours, switching from one lamp to another happens only at switching on of the projector and not during operation.
  • Page 89 10. Lamp Menu Image 10-4 Single mode operation: switching principle Dual mode Both lamps are working. When one lamp fails, the projector continues the projection using the remaining lamp. How to select the lamp mode ? 1. Press MENU to activate the Toolbar 2.

  • Page 90: History

    10. Lamp Menu When switching to single mode, returning to the dual mode will not be possible in the first 60 seconds, Dual in the menu is greyed out and LED1 is flickering, thereby preventing hot restrike which may damage the lamp. 10.4History How to view the history ? 1.

  • Page 91: Runtime Warning

    Image 10-8 Image 10-9 Lamp runtime reset as well as the lamp replacement can only be done by a Barco authorized technician. 10.6Runtime warning What can be done ? When the lamp has reached a certain predetermined runtime , a warning message will be displayed on the screen. The lamp runtime warning can be set in a range from 30 to 200 hours.
  • Page 92 10. Lamp Menu Image 10-10 Image 10-11 Lamp runtime reset as well as the lamp replacement can only be done by a Barco authorized technician. R5976367 BARCOIQ GRAPHICS/REALITY 200L/300/400 10062002...

  • Page 93: Image Files Menu

    11. Image files menu 11. IMAGE FILES MENU Overview • Flowchart • Load file • Edit file • Rename file • Copy • Delete 11.1Flowchart Overview of the Image files menu Image 11-1 Introduction to image files An image files contains the main characteristics of a source (number of active lines,...). The projector’s memory contains a list of files corresponding to the most common sources, these are the standard files (file extension= *.s).

  • Page 94: Load File

    11. Image files menu • Load : installation of a file for a new source • Edit : editing a loaded file to match the source specifications • Rename : renaming a file • Copy : copying a file to a new file •...
  • Page 95 11. Image files menu How to edit a file ? 1. Press MENU to activate the Toolbar 2. Press → to select the Image files item 3. Press ↓ to Pull down the Image files menu 4. Use ↑ or ↓ to select Edit (image 11-3) 5.
  • Page 96 11. Image files menu Advanced video settings The advanced button enables the advanced settings for a video source. Image 11-7 HI AGC Hold interval Image 11-6 The Comb filter is by default enabled. The AGC hold interval is the time interval in which the AGC is inhibited (AGC hold = no update in video amplitude measurement), the advanced parameter allows to choose a short or long hold interval.

  • Page 97: Rename File

    11. Image files menu The VCO range setting determines the frequency range of the VCO (Voltage Controlled Oscillator). The Cpmp (Charge pump current) sets the low pass filter current. Both VCO range & Cpmp are set by the image file, changing these settings is only indicated in for special purposes. The horizontal sync polarity setting can be useful in case of a bad shaped edge, one can choose between the leading (active low) or trailing (active high) edge.

  • Page 98: Copy

    11. Image files menu Image 11-12 11.5Copy How to copy a file ? 1. Press MENU to activate the Toolbar 2. Press → to select the Image files item 3. Press ↓ to Pull down the Image files menu 4. Use ↑ or ↓ to select copy (image 11-13) 5.

  • Page 99: Delete

    11. Image files menu 11.6Delete How to delete a file ? 1. Press MENU to activate the Toolbar 2. Press → to select the Image files item 3. Press ↓ to Pull down the Image files menu 4. Use ↑ or ↓ to select delete (image 11-16) 5.
  • Page 100 11. Image files menu R5976367 BARCOIQ GRAPHICS/REALITY 200L/300/400 10062002...

  • Page 101: Installation Menu

    12. Installation menu 12. INSTALLATION MENU Overview • Flowchart • Lens adjustments • Projector address • Orientation • Full screen representation • Language • Quick access keys • RS232 baudrate • Startup screen • Automatic startup • Textbox • Take screenshot •...

  • Page 102: Flowchart

    12. Installation menu 12.1Flowchart Overview of the Installation menu Image 12-1 12.2Lens adjustments What can be done ? Motorized lenses can be adjusted in the installation menu or via the dedicated keys on the remote. R5976367 BARCOIQ GRAPHICS/REALITY 200L/300/400 10062002...

  • Page 103: Projector Address

    12. Installation menu The following parameters can be adjusted: • Zoom • Focus • Shift How to Zoom/focus or shift ? 1. Press MENU to activate the Toolbar 2. Press → to select the Installation 3. Press ↓ to Pull down the Installation menu 4.
  • Page 104 12. Installation menu How to change the projector’s RC5 address ? 1. Press MENU to activate the Toolbar 2. Press → to select the Installation 3. Press ↓ to Pull down the Installation menu 4. Use ↑ or ↓ to select Projector address (image 12-5) 5.

  • Page 105: Orientation

    12. Installation menu Entering the new common address ? 1. Enter the new projector address with the digit keys on the RCU, the local keypad or the cursor keys. This address must be between 0 or 1. 12.4Orientation Projector orientations Depending on how the projector is oriented, the projector’s internal settings have to be adapted.

  • Page 106: Language

    12. Installation menu The show native resolution function on the other hand forces to use the native resolution of the source, see Show native resolution, page 58 The Full screen representation function overrules the show native resolution function. 12.6Language List of languages The list of selectable languages is depending on the software of the projector.

  • Page 107: Rs232 Baudrate

    12. Installation menu Image 12-12 How to program the quick access keys ? 1. Scroll through the menus to the desired menu item 2. Push the desired function key for 3 seconds The menu item is stored in the quick access key Factory pre-programmed functions -F1 : color depth -F2 : noise reduction...

  • Page 108: Startup Screen

    12. Installation menu 12.9Startup screen What can be done ? When the startup screen is enabled, the identification screen is displayed for a few seconds at startup. This startup screen can also be disabled. How to enable/disable the Startup screen? 1.

  • Page 109: Textbox

    12. Installation menu 12.11Textbox What can be done ? The textbox function allows to display or not the different sliderboxes used for instance for picture settings (contrast,...), it also affects the source information windows (displayed in the right lower corner of the screen). How to enable/disable the Textbox ? 1.

  • Page 110: Sliderbox Position

    12. Installation menu Image 12-16 Image 12-17 Image 12-18 Image 12-19 12.13Sliderbox position What can be done ? The sliderbox can be displayed anywhere on the screen, the position can be set in this menu. How to reposition the sliderbox? 1.

  • Page 111: Autoimage Setup

    12. Installation menu Image 12-20 Image 12-21 There is a coarse and a fine adjustment of the position, use ENTER (when sliderbox is displayed) to switch between the two. 12.14AutoImage Setup What can be done ? Autoimage allows to detect automatically the characteristics of the source (total pixels per line,...) and uses this information to adapt the image to the LCD panels.
  • Page 112 12. Installation menu Image 12-22 Image 12-23 How to perform AutoImage ? 1. press AutoImage on the RCU A textbox showing a progress bar is displayed. During the AUTOIMAGE measuring process the data source disappears temporarily (logo is displayed if back- ground is set to logo, see chapter 9.

  • Page 113: Change Password

    Each character is displayed as an asterisk. Image 12-25 Image 12-26 The new password is accepted if the new password and the confirmed password coincide. If the password is forgotten contact a Barco authorized technician. R5976367 BARCOIQ GRAPHICS/REALITY 200L/300/400 10062002...
  • Page 114 12. Installation menu R5976367 BARCOIQ GRAPHICS/REALITY 200L/300/400 10062002...

  • Page 115: Cleaning The Dustfilters

    A. Cleaning the dustfilters A. CLEANING THE DUSTFILTERS Overview • Dustfilters • Cleaning A.1 Dustfilters Location of the filters There are 4 filters located at different positions Filter1: Lamp 1 Filter2 : Lamp 2 Filter 3 : X-Cube filter Filter 4 : Input filter Image A-1 location of the filters lamp filter 1...
  • Page 116 A. Cleaning the dustfilters Image A-4 lamp & X-Cube filters removed Image A-3 Lamp filter removal Image A-6 Input filter removed Image A-5 Input filter removal If the airflow is falling under a predetermined treshold value a warning will be displayed on the screen. (im- age A-7) Image A-7 At that time it is strongly recommended to replace or clean the dustfilter under the X-cube.

  • Page 117: Standard Image Files

    B. Standard Image Files B. STANDARD IMAGE FILES B.1 Table overview Table overview The following standard image files are pre-programmed in the projector. Name Resolu- Fvert FHor Fpix Ptot Pact Ltot Lact tion 1600_48V 1600x600i 48,040 62,500 135,000 2160 1600 1600_60V 1600x1200 60,000...
  • Page 118 B. Standard Image Files Name Resolu- Fvert FHor Fpix Ptot Pact Ltot Lact tion MAC_LC 640x480 66,619 34,975 31,338 MAC_POR 640x870 74,996 68,846 57,280 MUSE 1172x518i 30,000 33,750 37,125 1172 1024 MXGA_60 1152x864 60,000 54,540 60,000 1456 1152 MXGA_70 1152x864 70,000 63,630 94,500...
  • Page 119 B. Standard Image Files Name Resolu- Fvert FHor Fpix Ptot Pact Ltot Lact tion SVGA_60V 800x600 60,317 37,879 40,000 1056 SVGA_72V 800x600 72,084 48,080 50,003 1040 SVGA_75 800x600 75,000 46,875 75,000 1056 SVGA_85 800x600 85,000 53,635 56,250 1048 SVGA_100 800x600 100,000 62,800 100,000...
  • Page 120 B. Standard Image Files R5976367 BARCOIQ GRAPHICS/REALITY 200L/300/400 10062002...
  • Page 121 Glossary GLOSSARY Automatic Gain Control: allows an automatic amplitude (gain) control of the incoming video signal ANSI 73.11 American power plug to connect the power cord to the wall outlet. CEE7 European power plug to connect the power cord to the wall outlet. Common address Default address.
  • Page 122 Glossary R5976367 BARCOIQ GRAPHICS/REALITY 200L/300/400 10062002...
  • Page 123 Index INDEX General menu 47–48 freeze Address 36–37, 97 pause Program General settings General Menu Projector address Getting started 29, 32, 34, 36, 38–39 setting address Adjustments Controlling the projector lens digital zoom lamp runtime Audio quick set up connection Quick Set up AutoImage lens...
  • Page 124 Index Menu 38–39, 41, 47, 54–57, 59, 61, 63–64, 67–74, 77, 79, 81–82, Native resolution 84–85, 87–88, 91–93, 95–97, 99–105, 107 No signal General menu background flowchart Image files menu 87–88, 91–93 copy file delete file Orientation edit file projector orientation flowchart load file rename file...
  • Page 125 Index Composite Video Textbox manual gain control Timer S-Video Video 20–21, 63–64 R5976367 BARCOIQ GRAPHICS/REALITY 200L/300/400 10062002...

This manual is also suitable for:

Barcoiq graphics 400Barcoiq reality 300Barcoiq reality 400Barcoiq graphics 300

Table of Contents
