- Page 1 BARCO PROJECTION SYSTEMS GRAPHICS 6300 R9001440 OWNER'S MANUAL Date : Rev. : Art. No. : 14072000 R5975879...
- Page 2 The use of shielded cables is required to comply within the limits of Part15 of FCC rules and EN55022. BARCO n.v./Projection Systems Noordlaan 5 B-8520 Kuurne Belgium Tel : +32/56/368211 Fax : +32/56/351651 E-mail : sales.bps@barco.com Visite Barco at the web : http://www.barco.com Printed in Belgium...
-
Page 3: Table Of Contents
Lamp Run Time History ............11-4 Projector address ............... 6-2 Dimming ..................11-5 Common Address ............... 6-2 BARCO logo ................11-5 Displaying a Projector Address..........6-2 Panel Adjustments ..............11-5 How to Program an Address into the RCU? ......6-2 Uniformity .................. -
Page 4: Unpacking And Dimensions
Unpacking and Dimensions UNPACKING AND DIMENSIONS Unpacking Pull To open 3 7 9 Projector dimensions 371.2 53.5 202.4 53.5 29.6 82.7 211.4 169.5 187.2 139.6 148.9 380.6 152.6 152.6 526.8 5975879 BARCOGRAPHICS 6300 29022000... -
Page 5: Battery Installation In The Rcu
1. the common address can be zero (0) or one (1). The standard RCU are setup for common address zero. To change the common address of the RCU, contact a BARCO service center. If it is necessary to program the projector address into the RCU, see chapter 'Controlling'. -
Page 6: Installation Guidelines
Installation Guidelines INSTALLATION GUIDELINES Read safety instruction before starting the installation. Installation Guidelines Careful consideration of things such as image size, ambient light level, projector placement and type of screen to use are critical to the optimum use of the projection system. Max. -
Page 7: Where To Install The Projector
BACK VIEW BACK VIEW * How to install a projection lens? The projector is supplied without any lens. The following lenses are available, or will become available (contact a Barco service center) as an option : QFD(1.27:1) R9840400 QFD(2.5:1) R9840290 QFD(1.4-2.1:1) - Page 8 Installation Guidelines QFD(4.5-6.0:1) R9840100 QFD(7:1) R9840410 How to install the lens? Take the lens out of its packing material. Open the lens cover of the projector by pivoting it up and take it off. image 1 Open both lens locks (B) by pulling them backwards. Unlock first by pulling clip (A) forwards. image 2 Put the lens on the lens holder.
-
Page 9: Location And Functions Of Control
Location and Functions of Control LOCATION AND FUNCTIONS OF CONTROL Front Panel Terminology The front panel terminology can be divided into 'Source & power connections' and 'Communication connections'. Source & Power Connections S-V IDE O T RIG R S232 IN R S232 O UT C OM M. -
Page 10: Communication Connections
Location and Functions of Control Communication Connections C OMM. PO RT VIDE O S-VIDE O S DI IEEE 139 4 TRIG MOUSE R S2 32 IN RS2 32 O UT MONITOR A UD IO IN AUDIO IN AUD IO IN H /C COMPU TER... -
Page 11: Remote Control
Location and Functions of Control b. Remote control This remote control includes a battery powered infrared (IR) transmitter that allows the user to control the projector remotely. This remote control is used for source selection, control, adaptation and set up. It includes automatic storing of : - picture controls (Brightness, Sharpness...) - settings Remote Control (RCU) - Page 12 Location and Functions of Control FREEZ : press to freeze the projected image. TEXT : when adjusting one of the image, e.g. controls during a meeting, the displayed bar scale can be removed by pressing 'TEXT' key first. To re-display the bar scale on the screen, press 'TEXT' key again. ENTER : to start up the adjustment mode or to confirm an adjustment or selection in the adjustment mode.
-
Page 13: Installation Set Up
Installation Set Up INSTALLATION SET UP Configuration 5HDU&HLOLQJ )URQW&HLOLQJ 5HDU7DEOH )URQW7DEOH é ê é ê é ê ADJUSTMENT MODE Select a path from below : RANDOM ACCESS INSTALLATION SERVICE Source 01 Select with then <ENTER> INSTALLATION <EXIT> to return. INPUT SLOTS 800 PERIPHERAL CONFIGURATION OSD COLOR... -
Page 14: Connections
Connections CONNECTIONS Power connection AC Power (mains) cord connection 90 to 240 VAC S -V IDE O I EEE 1394 TRIG M OUSE RS2 32 IN RS23 2 O UT C OMM. PO RT V ID EO S DI S DO MO NITO R C OMPUTER AUDIO I N... -
Page 15: Lamp Run Time
Connections Lamp Run Time Lamp run time is 750 hours. Operating the lamp longer than 750 hours may damage the Remaining projector. Please replace the lamp. Lamp run time 20 h WARNING Lamp run time is 750 hours Operating the lamp longer than 1000 hours may damage Lamp Run Time Warning the projector. -
Page 16: 5-Cable Input Slot (Slot 1)
Connections 5-cable Input Slot (slot 1) TRIG VIDEO S-VIDEO S DI IEE E 1394 MONITOR C OM PUTER Slot 1 selection : Configuration of the 5-cable input : ADJUST ENTER ADJUSTMENT MODE é ê Installation ENTER Select a path from below : é... -
Page 17: Computer Input/Monitor Output
Connections Computer input/Monitor output S-V IDEO TRIG RS232 IN RS232 O UT COM M. PORT VIDEO IEEE 1394 M OUSE M ONITO R COM PUTER AUDIO IN AUDIO IN AUDIO IN AUDIO IN Slot 2 selection : Video Input Input signal : Slot 3 Selection : TRIG RS232 IN... -
Page 18: S-Video Input
Connections S-Video Input Input signal : T RIG RS232 IN RS232 O UT COM M. PO RT VIDEO S-VIDEO IEEE 1394 M OUSE MONITO R COM PUTER AUDIO IN AUDIO IN AUDIO IN AUDIO IN A, B or C Lum a/Chroma VCR S-VHS Pin configuration mini DIN plug : Slot 4 Selection :... -
Page 19: Ieee 1394 Input
Connections connections : Slot 5 Selection : Note : When a RCVDS05 is connected to the projector, the SDI input is available by keying in 85 on the RCU. IEEE 1394 Input Communication Connections RS232 in / RS232 out S-VIDEO IEEE 1394 TRIG MOU SE... -
Page 20: Communication Port For Communication With Peripherals
Connections Communication port for communication with peripherals Connecting a RCVDS 05 to the projector. Connecting a VS05 to the projector TRIG Output MOUSE Audio Connections ENTER é ê ENTER é ê ENTER é ê ç è ENTER EXIT ADJUST 5975879 BARCOGRAPHICS 6300 120799... -
Page 21: Controlling
Controlling CONTROLLING Ceiling How to use the RCU? Screen IR sensor S -VIDE O TRIG RS23 2 IN RS232 O UT CO MM. PO RT V IDE O I EE E 13 94 MO USE MON ITO R AUDIO IN AUDIO IN A UD IO IN H /C... -
Page 22: Projector Address
Controlling Projector address a. Software set up of the projector address. b. How to control the projector or projectors. c. Using the RCU. Common Address Displaying a Projector Address. ADDRESS PROJECTOR ADDRESS How to Program an Address into the RCU? ADDRESS Picture controls with direct access. -
Page 23: Sound Controls With Direct Access
Controlling Tint Control Sharpness Control. Phase Control Freez key Sound controls with direct access. Volume Control Bass Control Treble Control Balance Control The Pause key. 5975879 BARCOGRAPHICS 6300 22022000... -
Page 24: The Selection Key
Controlling The Selection key. é ê ç è EXIT Zoom/Focus Change with é,ê,ç,è ENTER <ENTER> to Shift <EXIT> to return é ê ç è EXIT 5975879 BARCOGRAPHICS 6300 22022000... -
Page 25: Start Up Of The Adjustment Mode
Start up of the Adjustment Mode START UP OF THE ADJUSTMENT MODE Adjustment Mode All source parameters, picture and audio tuning, and geometry are made while in the 'Adjustment Mode'. Press the ADJUST or ENTER key to enter the 'Adjustment mode'. ADJUSTMENT MODE You are now in the 'Adjustment Mode'. -
Page 26: Auto Image Adjustment
Auto Image Adjust AUTO IMAGE ADJUSTMENT Auto Image Adjustment Push the cursor key é or ê to highlight 'Auto Image' and press ENTER. ADJUSTMENT MODE With auto image, it is possible to switch the auto image function 'on' or 'off' and to adjust an existing image when the auto image function is off. -
Page 27: Random Access Adjustment Mode
Random Access Adjustment Mode RANDOM ACCESS ADJUSTMENT MODE Starting up the Random Access Adjustment Mode ADJUSTMENT MODE é ê to highlight 'Random Access' and then press ENTER. Push the Select a path from below : AUTO IMAGE RANDOM ACCESS INSTALLATION SERVICE Source 01 Select with... -
Page 28: File Service
Random Access Adjustment Mode File Service RANDOM ACCESS é ê ADJUSTMENT MODE ENTER FILE SERVICE PICTURE TUNING GEOMETRY EXIT ADJUST Select with The following file manipulations are possible : then <ENTER> FILE SERVICE <EXIT> to return. - Load : installation of a file for a new source. LOAD - Edit : editing a loaded file to the source specs. -
Page 29: Edit File
Random Access Adjustment Mode Edit File FILE SERVICE LOAD EDIT RENAME é ê COPY ENTER EDIT FILE Select with ENTER then <ENTER> Filename Resolution <EXIT> to return. ----------------------------------------------------- Video525.s01 1 675x240i Video525.c01 1 675x240i Video525.c02 1 675x240i ----------------------------------------------------- Active file : Video525.c50 Select with <ENTER>... - Page 30 Random Access Adjustment Mode Read AMDS Options Source Number EDIT FILE OPTIONS Source number Clamp position [leading] Clamp delay Clamp width Field polarity [pos] Clamp Position Field select [both] Vertical refresh [sync] Vertical sync polarity [leading] ENTER Select with <ENTER> to toggle to change value Clamp Delay <EXIT>...
-
Page 31: Delete
Random Access Adjustment Mode Rename é ê FILE SERVICE ENTER LOAD EDIT é ê RENAME ENTER COPY DELETE Select with RENAME FILE then <ENTER> <EXIT> to return. Filename Resolution ----------------------------------------------------- Video525.s01 1 675x240i Video525.c01 1 675x240i Video525.c02 1 675x240i ----------------------------------------------------- Active file : Video525.c50 Select with <ENTER>... -
Page 32: File Options
Random Access Adjustment Mode ENTER CONFIRM EXIT DELETE FILE Delete file: Video525.c01? <ENTER> to confirm <EXIT> to return File Options é ê ENTER FILE SERVICE File Sort LOAD EDIT RENAME COPY Press ENTER to toggle between [name] and [index] DELETE [name] : The files in the file list will be sorted on the file name. -
Page 33: Color Temperature
Random Access Adjustment Mode Color Temperature é ê PICTURE TUNING ENTER CTI [ON] COLOR TEMPARATURE GAMMA DECODING [EBU] DYNAMIC COLOR DEPTH COLOR TEMPERATURE PROJECTOR WHITE COMPUTER 9300K VIDEO 6500K FILM 5400K BROADCAST 3200K CUSTOM BALANCE Select with then <ENTER> <EXIT> to return. é... -
Page 34: Input Balance
Random Access Adjustment Mode Dynamic Color Depth PICTURE TUNING CTI [ON] COLOR TEMPERATURE GAMMA é ê DECODING [EBU] ENTER DYNAMIC COLOR DEPTH NOISE REDUCTION ç è INPUT BALANCE Select with then <ENTER> <EXIT> to return. EXIT DYNAMIC COLOR DEPTH Noise Reduction PICTURE TUNING CTI [ON] STILL VIDEO [ON]... -
Page 35: Audio Tuning
Random Access Adjustment Mode Audio Tuning é ê ENTER RANDOM ACCESS ADJUSTMENT MODE FILE SERVICE PICTURE TUNING AUDIO TUNING GEOMETRY AUDIO TUNING VOLUME BALANCE B A S S TREBLE MUTE [OFF] FADE MODE [STEREO] VIDEO - AUDIO LOCK Select with then <ENTER>... -
Page 36: Mode [Stereo]/[Mono]
Random Access Adjustment Mode Mode [stereo]/[mono] AUDIO TUNING VOLUME BALANCE B A S S TREBLE é ê MUTE [OFF] FADE ENTER MODE [STEREO] VIDEO - AUDIO LOCK Select with then <ENTER> <EXIT> to return. FADE Video - Audio lock é ê... -
Page 37: Shift
Random Access Adjustment Mode Shift The image can be shifted in a horizontal or vertical direction. To start up the shift action : GEOMETRY é ê SHIFT ENTER SIZE SIDE KEYSTONE é ê BLANKING ASPECT RATIO [4:3] ç è OPTIONS Select with then <ENTER>... -
Page 38: Blanking
Random Access Adjustment Mode Blanking GEOMETRY SHIFT SIZE SIDE KEYSTONE BLANKING é ê ASPECT RATIO [4:3] OPTIONS ENTER Select with then <ENTER> <EXIT> to return. BLANKING BOTTOM LEFT RIGHT R E S E T Top blanking Select with then <ENTER> <EXIT>... -
Page 39: Aspect Ratio [4:3]/[16:9]
Random Access Adjustment Mode Aspect Ratio [4:3]/[16:9] GEOMETRY SHIFT SIZE é ê SIDE KEYSTONE ENTER BLANKING ASPECT RATIO [4:3] OPTIONS Select with then <ENTER> <EXIT> to return. Options é ê ENTER GEOMETRY SHIFT SIZE SIDE KEYSTONE BLANKING ASPECT RATIO [4:3] OPTIONS GEOMETRY OPTIONS ENTER... -
Page 40: Installation Mode
Installation Mode INSTALLATION MODE Starting up the Installation Mode ADJUSTMENT MODE é ê to highlight 'Installation Mode' and then Push the Select a path from below : press ENTER. AUTO IMAGE RANDOM ACCESS INSTALLATION SERVICE Source 01 INSTALLATION INPUT SLOTS NO SIGNAL LENS TEXT BOX POSITION... -
Page 41: No Signal
Installation Mode +800 peripheral No Signal INSTALLATION INPUT SLOTS é ê NO SIGNAL LENS ENTER TEXT BOX POSITION QUICK ACCESS KEYS START UP MODE é ê more ... ENTER NO SIGNAL é ê COLOR [Blue] SHUTDOWN [Off] ENTER Shutdown time : 5 min é... -
Page 42: Text Box Position
Installation Mode Text Box Position INSTALLATION é ê INPUT SLOTS ENTER NO SIGNAL LENS TEXT BOX POSITION QUICK ACCESS KEYS START UP MODE more ... Select with then <ENTER> <EXIT> to return. TEXT BOX POSITION ALIGN : [CENTER] Select with then <ENTER>... -
Page 43: Peripheral
Installation Mode 800 Peripheral Output module selection. INSTALLATION 800 PERIPHERALS CONFIGURATION OSD COLOR INTERNAL PATTERNS SWITCHING MODE more ... é ê ENTER Select with then <ENTER> é ê <EXIT> to return. 800 PERIPHERAL OUTPUT MODULE [STANDARD] Infrared Communication. INFRARED [PPM] é... -
Page 44: Internal Patterns
Installation Mode Internal Patterns INSTALLATION é ê 800 PERIPHERALS ENTER CONFIGURATION OSD COLOR INTERNAL PATTERNS é ê SWITCHING MODE more ... Select with then <ENTER> <EXIT> to return. INTERNAL PATTERNS OUTLINE HATCH COLOR BARS MULTIBURST CHECKER BOARD PAGE CHAR ALPHA_NUMERIC CHAR CHARACTER SETS Select with then <ENTER>... - Page 45 Installation Mode 10-6 5975879 BARCOGRAPHICS 6300 14072000...
-
Page 46: Service Mode
I2C DIAGNOSIS MORE... Select with then <ENTER> <EXIT> to return. SERVICE BARCO CHANGE PASSWORD CHANGE LANGUAGE GRAPHICS 6300 IDENTIFICATION Enter new password ENGLISH CHANGE PASSWORD Proj. address : 001 x x x x CHANGE LANGUAGE Soft. version : 3.0 CHANGE PROJ. ADDRESS... -
Page 47: Identification
ENTER then <ENTER> then <ENTER> <EXIT> to return. <EXIT> to return. Select with then <ENTER> <EXIT> to return. BARCO LOGO SERVICE I2C DIAGNOSIS D C A BARCO LOGO STATUS : [ON] DECODER 12H # # # PANEL ADJUSTMENTS... -
Page 48: Change Password
How to enable or disable the password function ? The password function is enabled when the password strap on the controller module is installed. Consult an authorised Barco service technician to change the strap position. How to change the password ? Push the cursor key é... -
Page 49: Common Address
Service Mode Common Address Every projector listens to a common address. This common address can be set to '0' or '1'. When the RCU is programmed with that common CHANGE PROJ. ADDRESS address, every projector with that same common address will follow Projector address 001 up the commands given by that RCU. -
Page 50: Dimming
<ENTER> <EXIT> to return. BARCO logo The BARCO logo can be added to the image, in overlay or on a background, on any place on the screen. SERVICE To add the BARCO logo or to change a setting in the BARCO logo... -
Page 51: Uniformity
Service Mode Uniformity Changing these settings may seriously affect the perform- ance of the projector. SERVICE BARCO LOGO PANEL ADJUSTMENTS When Uniformity is selected in the Service Mode selection menu, the UNIFORMITY following warning will be displayed : PRESET INPUT BALANCE I2C DIAGNOSIS MORE... - Page 52 Appendix A : Standard Source Set Up Files STANDARD SOURCE SET UP FILES NAME RESOLUTION FVERT FHOR FPIX PTOT PACT LTOT LACT Name : name of file, contains the settings 8514_A 1024 X 384I 43,479 35,522 44,900 1264 1024 Resolution : image resolution, when fol- lowed by ...I means interlaced.
-
Page 53: Standard Source Set Up Files
Appendix A : Standard Source Set Up Files NAME RESOLUTION FVERT FHOR FPIX PTOT PACT LTOT LACT PC98_1 640 X 400 56,416 24,823 21,050 848 PC98_2 1120 X 375I 39,994 32,835 47,840 1457 1120 PC98_3 1120 X 750 60,000 50,000 78,569 1571 1120 S1152_66 1152 X 900... -
Page 54: Lenses
Lenses LENSES Lens Cleaning Procedure To minimize the possibility of damaging the optical coating or scratching exposed lens surface, we have developed recommendations for cleaning the lens. FIRST, we recommend you try to remove any material from the lens by blowing it off with clean, dry deionized air. DO NOT use any liquid to clean the lenses. -
Page 55: Lenses
= 5.86 x SW + 0.15 + 0.0121/SW Inch = 4.29 x SW - 0.79 + 1.395/SW = 5.86 x SW + 5.91 + 18.755/SW Lens program to calculate the projector distance is available on the BARCO webside : http://www.barco.com/projecti/cusserv/index.htm 5975879 BARCOGRAPHICS 6300 14072000... -
Page 56: Source Numbers 81 - 86 And 91 - 96
Source Numbers 80 - 89 and 90 - 99 SOURCE NUMBERS 81 - 86 AND 91 - 96 Projector without any 800 peripheral connected. Projector with a 800 peripheral connected. Source numbers 91 - 99. - Page 57 Source Numbers 80 - 89 and 90 - 99 Source numbers 81 - 86...
