Attaching the transparent protector
Fig. 9:

3.3 Power Source

The Regesta-PRO ER B can be powered through DC voltage. Nominal power voltage is 48 V DC.
Note
Before connecting the router, please read the following instructions carefully.
Workplace. Main characteristics
• The device should not be placed amongst papers, magazines or other elements that could hinder natural air circu-
lation.
• Knocks and/or strong vibrations should be avoided during transport, operation and storage.
Warning
Electric current in power cables, telephone lines and communication cables is dangerous. To prevent
electric shocks, before installing, handling or opening the equipment covers, connect and disconnect
the cables following the steps set forth in

3.3.1 Connecting the Power Supply

To connect the power supply to the router, please follow the steps set forth in
Warning
To avoid electric shocks, residual current circulation and other unwanted effects, also affecting commu-
nications, the following is recommended:
All interconnected communication devices should be plugged to THE SAME GROUNDED POWER
OUTLET, which should, at the same time, be of good quality (lower than 10 ohms).
Whether the workplace is provided with an uninterrupted power supply system (UPS), regulated supply
or it is independent from the rest (such as lighting, etc.); it is highly recommended that all data devices
should be connected to the same power source. This will avoid operating and premature aging prob-
lems of drivers and other components.
Regesta-PRO ER B Router
To Connect on page 11 and To Disconnect
To Connect
3 Components and Power Supply
on page 11.
on page 11.
