3 Components and Power Supply
Fig. 20: Mounting points
The device is now ready for rack installation.
Fig. 21: Rack kit installed
3.4 Plug-in modules
The Teldat Connect-FW5G does not have plug-in modules.
Reserved for future use.
3.5 Power source
The Teldat Connect-FW5G router is powered through an external AC/DC power adapter.
Warning
The equipment must be used with the power supply provided by the manufacturer.
To power the router, plug the power supply into the mains supply and the DC connector.
Fig. 22: DC Connector
14
Teldat S.A.
Teldat Connect-FW5G
