Teldat S.A.
3.4 Power source
The Teldat iM8-Cx router is powered through two internal AC/DC sources. The Teldat iM8-Cx has two power inputs
and two power supplies that operate simultaneously. It can operate one, the other, or both at once. If Teldat iM8-Cx
is powered by the two power supplies and one of them fails, the other acts as a backup.
Warning
The equipment must be used with the power supply provided by the manufacturer.
Workplace Conditions. Main Characteristics
• Avoid humid and/or dusty locations.
• Direct exposure to sunlight should be avoided, as well as other heat sources. The device should not be placed
amongst papers, magazines or other elements that could hinder natural air circulation.
• The device should not be placed very close to strong electromagnetic fields such as speakers, engines, etc.
• Knocks and/or strong vibrations should be avoided during transport, operation and storage.
Warning
The electric current in power cables, telephone lines and communication cables is dangerous. To pre-
vent electric shocks, before installing, handling or opening the equipment covers, connect and discon-
nect the cables following the steps set forth in
3.4.1 Internal power source
To connect the power supply to the device, please follow the steps under section
To avoid electric shocks, residual current circulation and other unwanted effects that affect communications, the fol-
lowing is recommended:
Warning
All interconnected communication devices should be plugged to THE SAME GROUNDED POWER
OUTLET, which should at the same time be of good quality (lower than 10 ohms).
We recommend connecting all devices to the same power source regardless of whether the workplace
is provided with an uninterrupted power supply system (UPS), a regulated supply or is independent of
other power supplies (such as lighting, etc.). This will help to prevent malfunctions and premature aging
of drivers and other components.
3.4.1.1 Connecting
• Ensure that the on/off power supply switch is in the OFF position.
• Connect all data cables.
• Connect the power supply to the device.
• Set the device's on/off power supply switch in the ON position.
3.4.1.2 Disconnecting
• Set the on/off power supply switch in the OFF position.
• Disconnect the power supply from the device.
• Disconnect the data cables.
Teldat Router iM8-Cx
Connecting
on page 7 and
Disconnecting
Connecting
3 Components and Power Supply
on page 7.
on page 7.
7
