The following example shows accessing Terminal 18 to see
the default setting.
1. Press [Main Menu] twice, scroll to parameter group
5-** Digital In/Out and press [OK].
2. Scroll to parameter group 5-1* Digital Inputs and
press [OK].
3.
Scroll to 5-10 Terminal 18 Digital Input. Press [OK] to
access function choices. The default setting Start is
shown.
5.4 International/North American Default
Parameter Settings
Setting 0-03 Regional Settings to [0]International or [1] North
America changes the default settings for some parameters.
Table 5.1 lists those parameters that are effected.
Parameter International
default parameter
value
0-03 Regional International
Settings
1-20 Motor Power See Note 1
[kW]
1-21 Motor Power See Note 2
[HP]
1-22 Motor Voltage 230V/400V/575V
®
VLT AutomationDrive Operating
Instructions
1-23 Motor
Frequency
3-03 Maximum
Reference
3-04 Reference
Function
4-13 Motor Speed
High Limit [RPM]
See Note 3 and 5
4-14 Motor Speed
High Limit [Hz]
See Note 4
4-19 Max Output
Frequency
4-53 Warning Speed
High
5-12 Terminal 27
Digital Input
5-40 Function Relay No operation
6-15 Terminal 53
High Ref./Feedb.
Value
6-50 Terminal 42
Output
14-20 Reset Mode
Table 5.1 International/North American Default Parameter Settings
Note 1: 1-20 Motor Power [kW] is only visible when
0-03 Regional Settings is set to [0] International.
Note 2: 1-21 Motor Power [HP], is only visible when
0-03 Regional Settings is set to [1] North America.
Note 3: This parameter is only visible when 0-02 Motor Speed
Unit is set to [0] RPM.
Note 4: This parameter is only visible when 0-02 Motor Speed
Unit is set to [1] Hz.
Note 5: The default value depends on the number of motor
poles. For a 4 poled motor the international default value is
1500RPM and for a 2 poled motor 3000RPM. The
corresponding values for North America is 1800 and
3600RPM, respectively.
Changes made to default settings are stored and available
for viewing in the quick menu along with any programming
North American
entered into parameters.
default parameter
value
North America
See Note 1
See Note 2
208V/460V/575V
®
MG.33.AJ.02 - VLT is a registered Danfoss trademark
Parameter International
default parameter
value
50Hz
50Hz
Sum
1500RPM
50Hz
132Hz
1500RPM
Coast inverse
50
No operation
Manual reset
1. Press [Quick Menu].
2. Scroll to Q5 Changes Made and press [OK].
North American
default parameter
value
60Hz
60Hz
External/Preset
1800RPM
60Hz
5
120Hz
1800RPM
External interlock
No alarm
60
Speed 4-20mA
Infinite auto reset
33
5
