Application Set-Up Examples
FC
+24 V
12
+24 V
13
D IN
18
D IN
19
COM
20
D IN
27
D IN
29
D IN
32
D IN
33
D IN
37
+10 V
50
A IN
53
A IN
54
COM
55
A OUT
42
COM
39
01
02
03
04
05
06
Table 6.13 Using SLC to Set a Relay
®
VLT
AutomationDrive Operating
Instructions
Parameters
Function
Setting
4-30 Motor
Feedback Loss
Function
[1] Warning
4-31 Motor
100RPM
Feedback Speed
Error
4-32 Motor
5 sec
Feedback Loss
Timeout
7-00 Speed PID
[2] MCB 102
Feedback Source
17-11 Resolution
1024*
(PPR)
13-00 SL
[1] On
Controller Mode
13-01 Start Event [19] Warning
13-02 Stop Event [44] Reset key
13-10 Comparato
[21] Warning
r Operand
no.
13-11 Comparato
[1] ≈*
r Operator
13-12 Comparato
90
r Value
13-51 SL
[22]
Controller Event
Comparator 0
13-52 SL
[32] Set
Controller Action
digital out A
low
5-40 Function
[80] SL digital
Relay
output A
* = Default Value
Notes/comments:
If the limit in the feedback
monitor is exceeded, Warning 90
will be issued. The SLC monitors
Warning 90 and in the case that
Warning 90 becomes TRUE then
Relay 1 is triggered.
External equipment may then
indicate that service may be
required. If the feedback error
goes below the limit again
within 5 sec. then the drive
continues and the warning
disappears. But Relay 1 will still
be triggered until [Reset] on the
LCP.
®
MG.33.AJ.02 - VLT
is a registered Danfoss trademark
Table 6.14 Mechanical Brake Control
1 - 7 6
C u r r e n t
S p e e d
1 - 7 1
S t a r t ( 1 8 )
S t a r t
r e v e r s i n g ( 1 9 )
R e l a y o u t p u t
O p e n
C l o s e d
Parameters
Function
Setting
5-40 Function
[32] Mech.
Relay
brake ctrl.
5-10 Terminal 18
[8] Start*
Digital Input
5-11 Terminal 19
[11] Start
Digital Input
reversing
1-71 Start Delay
0.2
1-72 Start
[5] VVC+/
Function
FLUX
Clockwise
1-76 Start Current Im,n
2-20 Release
App.
Brake Current
dependent
2-21 Activate
Half of
Brake Speed
nominal slip
[RPM]
of the motor
* = Default Value
Notes/comments:
T i m e
2 - 2 1
1 - 7 1
2 - 2 1
45
6
6
