Specifications
Mains Supply 3 x 525- 690V AC
FC 302
1)
High/ Normal Load
Typical Shaft output at 550V [kW]
Typical Shaft output at 575V [HP]
Typical Shaft output at 690V [kW]
Enclosure IP21, 55
Output current
Continuous
(3 x 525-550V) [A]
Intermittent (60 sec overload)
(3 x 525-550V) [A]
Continuous
(3 x 551-690V) [A]
Intermittent (60 sec overload)
(3 x 551-690V) [A]
Continuous KVA
(at 550V) [KVA]
Continuous KVA
(at 575V) [KVA]
Continuous KVA
(at 690V) [KVA]
Max. input current
Continuous
(3 x 525-690V) [A]
Intermittent (60 sec overload)
(3 x 525-690V) [A]
Additional specifications
Max. cable size, mains, motor,
load share and brake [mm
(AWG)]
Estimated power loss
4)
at rated max. load [W]
Weight,
enclosure IP21, IP55 [kg]
4)
Efficiency
®
VLT AutomationDrive Operating
Instructions
P11K
HO NO
7.5 11
11 15
11 15
B2
14 19
22.4 20.9
13 18
20.8 19.8
13.3 18.1
12.9 17.9
15.5 21.5
15 19.5
23.2 21.5
2
228
0.98
®
MG.33.AJ.02 - VLT is a registered Danfoss trademark
P15K P18K
HO NO HO
11 15 15
15 20 20
15 18.5 18.5
B2 B2
19 23 23
30.4 25.3 36.8
18 22 22
28.8 24.2 35.2
18.1 21.9 21.9
17.9 21.9 21.9
21.5 26.3 26.3
19.5 24 24
31.2 26.4 38.4
35 (1/0)
285 335
27
0.98 0.98
P22K
NO HO NO
18.5 18.5 22
25 25 30
22 22 30
B2
28 28 36
30.8 44.8 39.6
27 27 34
29.7 43.2 37.4
26.7 26.7 34.3
26.9 26.9 33.9
32.3 32.3 40.6
29 29 36
31.9 46.4 39.6
375
0.98
69
10 10
