3.1.2 Start Up Check List

CAUTION
Before applying power to the unit, inspect the entire installation as detailed in Table 3.1. Check mark those items when
completed.
Inspect for
Auxiliary equipment
3
3
Cable routing
Control wiring
Cooling clearance
EMC considerations
Environmental considerations
Fusing and circuit breakers
Grounding
Input and output power wiring
Panel interior
Switches
Vibration
Table 3.1 Start Up Check List
22
®
VLT
AutomationDrive Operating
Instructions
Description
Look for auxiliary equipment, switches, disconnects, or input fuses/circuit breakers
that may reside on input power side of frequency converter or output side to
motor. Examine their operational readiness and ensure that they are ready in all
respects for operation at full speed.
Check function and installation of any sensors used for feedback to frequency
converter
Remove power factor correction caps on motor(s), if present
Ensure that input power, motor wiring, and control wiring are separated or in
three separate metallic conduits for high frequency noise isolation
Check for broken or damaged wires and loose connections
Check that control wiring is isolated from power and motor wiring for noise
immunity
Check the voltage source of the signals, if necessary
The use of shielded cable or twisted pair is recommended. Ensure that the shield
is terminated correctly.
Measure that top and bottom clearance is adequate to ensure proper air flow for
cooling
Check for proper installation regarding electromagnetic compatibility
See equipment label for the maximum ambient operating temperature limits
Humidity levels must be 5-95% non-condensing
Check for proper fusing or circuit breakers
Check that all fuses are inserted firmly and in operational condition and that all
circuit breakers are in the open position
The unit requires a ground wire from its chassis to the building ground
Check for good ground connections that are tight and free of oxidation
Grounding to conduit or mounting the back panel to a metal surface is not a
suitable ground
Check for loose connections
Check that motor and mains are in separate conduit or separated screened cables
Inspect that the unit interior is free of dirt, metal chips, moisture, and corrosion
Ensure that all switch and disconnect settings are in the proper position
Check that the unit is mounted solidly or that shock mounts are used, as
necessary
Look for any unusual amount of vibration the unit may be subjected to
®
MG.33.AJ.02 - VLT
is a registered Danfoss trademark
