Installation
Illustration 2.5 Typical Electrical Connection
1
PLC
2
Frequency converter
3
Output contactor (Generally not recommended)
4
Earth (grounding) rail (PE)
5
Cable insulation (stripped)
®
VLT
AutomationDrive Operating
Instructions
6
Min. 200mm (7.9in) between control cables, motor and mains
7
Motor, 3-phase and PE
8
Mains, 3-phase and reinforced PE
9
Control wiring
10
Equalising min. 16mm
®
MG.33.AJ.02 - VLT
is a registered Danfoss trademark
2
(0.025in)
2
2
11
