Application Set-Up Examples

6 Application Set-Up Examples

6.1 Introduction

NOTE
A jumper wire may be required between terminal 12 (or 13)
and terminal 27 for the frequency converter to operate when
using factory default programming values. See 2.4.1.1 Jumper
Terminals 12 and 27 for details.
The examples in this section are intended as a quick
reference for common applications.
•
Parameter settings are the regional default values
unless otherwise indicated (selected in
0-03 Regional Settings)
•
Parameters associated with the terminals and their
settings are shown next to the drawings
•
Where switch settings for analog terminals A53 or
A54 are required, these are also shown

6.2 Application Examples

Table 6.1 AMA with T27 Connected
®
VLT AutomationDrive Operating
Instructions
Parameters
Function Setting
1-29 Automatic [1] Enable
Motor Adaptation complete
AMA
(AMA)
5-12 Terminal 27 [2]* Coast
Digital Input inverse
* = Default Value
Notes/comments: Parameter
group 1-2* must be set
according to motor
®
MG.33.AJ.02 - VLT is a registered Danfoss trademark
1-29 Automatic
Motor Adaptation
(AMA)
5-12 Terminal 27
Digital Input
* = Default Value
Notes/comments: Parameter
group 1-2* must be set
according to motor
Table 6.2 AMA without T27 Connected
6-10 Terminal 53
Low Voltage
6-11 Terminal 53
High Voltage
6-14 Terminal 53
Low Ref./Feedb.
Value
6-15 Terminal 53
High Ref./Feedb.
Value
* = Default Value
Notes/comments:
Table 6.3 Analog Speed Reference (Voltage)
Parameters
Function Setting
[1] Enable
complete
AMA
[0] No
operation
Parameters
Function Setting
0.07V*
10V*
0RPM
1500RPM
41
