Specifications
FC 300
Bussmann
[kW] 2)
Type JFHR2
0.25-0.37 FWX-5
0.55-1.1 FWX-10
1.5 FWX-15
2.2 FWX-20
3.0 FWX-25
3.7 FWX-30
5.5 FWX-50
7.5 FWX-60
11 FWX-80
15-18.5 FWX-125
22 FWX-150
30 FWX-200
37 FWX-250
Table 10.7 200-240V, Frame Sizes A, B, and C
1) KTS-fuses from Bussmann may substitute KTN for 240V frequency converters.
2) FWH-fuses from Bussmann may substitute FWX for 240V frequency converters.
3) A6KR fuses from FERRAZ SHAWMUT may substitute A2KR for 240V frequency converters.
4) A50X fuses from FERRAZ SHAWMUT may substitute A25X for 240V frequency converters.
FC 300 Bussmann
[kW] Type RK1
0.37-1.1 KTS-R-6
1.5-2.2 KTS-R-10
3 KTS-R-15
4 KTS-R-20
5.5 KTS-R-25
7.5 KTS-R-30
11 KTS-R-40
15 KTS-R-50
18 KTS-R-60
22 KTS-R-80
30 KTS-R-100
37 KTS-R-125
45 KTS-R-150
55 KTS-R-200
75 KTS-R-250
Table 10.8 380-500V, Frame Sizes A, B, and C
®
VLT AutomationDrive Operating
Instructions
Recommended max. fuse
Littel fuse
JFHR2
-
-
-
-
-
-
-
-
-
-
L25S-150
L25S-200
L25S-250
Recommended max. fuse
Bussmann Bussmann
Type J Type T
JKS-6 JJS-6
JKS-10 JJS-10
JKS-15 JJS-15
JKS-20 JJS-20
JKS-25 JJS-25
JKS-30 JJS-30
JKS-40 JJS-40
JKS-50 JJS-50
JKS-60 JJS-60
JKS-80 JJS-80
JKS-100 JJS-100
JKS-125 JJS-125
JKS-150 JJS-150
JKS-200 JJS-200
JKS-250 JJS-250
®
