Programming
5.3 Control Terminal Programming
Examples
Control terminals can be programmed.
•
Each terminal has specified functions it is capable
of performing.
•
Parameters associated with the terminal enable
the function.
See Table 2.5 for control terminal parameter number and
default setting. (Default setting can change based on the
selection in 0-03 Regional Settings).
The following example shows accessing Terminal 18 to see
the default setting.
1. Press [Main Menu] twice, scroll to parameter
group 5-** Digital In/Out and press [OK].
14.6%
Main Menu
2-** Brakes
3-** Reference / Ramps
4-** Limits / Warnings
5-** Digital In/Out
Figure 5.9 6-15 Terminal 53 High Ref./Feedb. Value
2. Scroll to parameter group 5-1* Digital Inputs and
press [OK].
14.7%
Digital In/Out
5-0* Digital I/O mode
5-1* Digital Inputs
5-4* Relays
5-5* Pulse Input
Figure 5.10 Digital In/Out
MG16E222
Instruction Manual
5.4 International/North American Default
Setting 0-03 Regional Settings to [0] International or [1]
North America changes the default settings for some
parameters. Table 5.1 lists those parameters that are
0.00A 1(1)
effected.
0-03 Regional
Settings
1-20 Motor Power
[kW]
1-21 Motor Power
[HP]
1-22 Motor Voltage 230 V/400 V/575 V
1-23 Motor
0.00A 1(1)
Frequency
5-**
3-03 Maximum
Reference
3-04 Reference
Function
4-13 Motor Speed
High Limit [RPM]
See Note 3 and 5
4-14 Motor Speed
High Limit [Hz]
See Note 4
4-19 Max Output
Frequency
4-53 Warning Speed
High
5-12 Terminal 27
Digital Input
5-40 Function Relay Alarm
