Frame Sizes And Power Ratings - Danfoss VLT AutomationDrive Operating Instructions Manual

Introduction

1.5 Frame Sizes and Power Ratings

Volts A1 A2
200-240 0.25-1.5 0.25-2.2 3.0-3.7
380-480 0.37-1.5 0.37-4.0 5.5-7.5
525-600 N/A N/A 0.75-7.5
525-690 N/A N/A
Table 1.2 Frames Sizes and Power Ratings
®
VLT AutomationDrive Operating
Instructions
A3 A4 A5 B1
0.25-2.2 0.25-3.7 5.5-7.5
0.37-4.0 0.37-7.5 11-15
N/A 0.75-7.5 11-15
N/A N/A N/A N/A
®
MG.33.AJ.02 - VLT is a registered Danfoss trademark
Frame size (kW)
B2 B3 B4 C1
11 5.5-7.5 11-15 15-22
18.5-22 11-15 18.5-30 30-45
18.5-22 11-15 18.5-30 30-45
11-22 N/A N/A N/A
C2 C3 C4
30-37 18.5-22 30-37
55-75 37-45 55-75
55-90 37-45 55-90
30-75 N/A N/A
