Appendix: Resource Usage Summary

4 Appendix: Resource Usage Summary
The following table shows Adaptive FIR filter demo resource usage summary.
Device: SmartFusion2 device
Die: M2S010
Package: 484 FBGA
The following table shows Adaptive FIR filter resource usage summary.
Device: SmartFusion2 device
Die: M2S090TS
Package: 484 FBGA
The following table shows MACC blocks usage summary.
Table 6 • Adaptive FIR Filter Demo Resource Usage Summary
Type Used Total
4LUT 2834 12084 23.45
DFF 2827 12084 23.39
RAM64x18 0 22
RAM1Kx18 11 21
MACC 13 22
Table 7 • Adaptive FIR Filter Demo Resource Usage Summary
Type Used Total
4LUT 2833 86184 3.29
DFF 2827 86184 3.28
RAM64x18 0 112
RAM1K18 11 109
MACC 13 84
Table 8 • MACC Blocks Usage Summary
CoreFIR CoreFFT LMS_ALGO
8 04 1
