SmartFusion2 SoC FPGA - Adaptive FIR Filter Demo
2.5.1
Setting Up the Demo Design for SmartFusion2 Security
Evaluation Kit
The following steps describe how to setup the hardware demo for Security Evaluation kit:
1.
Connect the jumpers on the SmartFusion2 Security Evaluation kit board as shown in the following
table.
Table 3 •
SmartFusion2 Security Evaluation Kit Jumper Settings
Jumper
Configuration
J23
–
Close
Open
J22
–
Close
Open
J24
Open
J8
–
Close
Open
Open
J3
–
1. Ensure that the power supply switch SW7 is OFF while making the jumper connections.
2. Connect the Power supply to the J6 connector, switch on the power supply switch, SW7.
2.
Connect the FlashPro4 programmer to the J5 connector of the SmartFusion2 Security Evaluation kit
board.
3.
Connect the Host PC USB port to the P1 Mini USB connector on the SmartFusion2 Security
Evaluation kit board using the USB Mini-B cable.
The following figure shows the board setup for running the DSP Adaptive FIR filter demo on the
SmartFusion2 Security Evaluation kit.
Comments
Jumper to select switch-side multiplexer (MUX) inputs of A or B to the lineside.
Pin 1-2 (Input A to the lineside) that is on board 125 MHz differential clock
oscillator output will be routed to lineside.
Pin 2-3 (Input B to the lineside) that is external clock required to source through
SMA connectors to the lineside.
Jumper to select the output enables control for the lineside outputs.
Pin 1-2 (Lineside output enabled)
Pin 2-3 (Lineside output disabled)
Jumper to provide the VBUS supply to USB when using in Host mode.
JTAG selection jumper to select between RVI header or FP4 header for
application debug.
Pin 1-2 FP4 for SoftConsole/FlashPro
Pin 2-3 RVI for Keil™ ULINK™/IAR J-Link
Pin 2-4 for Toggling JTAG_SEL signal remotely using GPIO capability of FT4232
chip.
Jumpers to select either SW2 input or signal ENABLE_FT4232 from FT4232H
chip.
DG0441 Demo Guide Revision 7.0
®
10
