Appendix A: Technical Specifications

Operation Mode
Program memory
Aspirating/Dispensing Speed
Auto-calibration
Piston Motor
Power Saving Feature
Power Adaptor
Audible Alerts
Autoclavable
Operating Temperature
Operating Humidity
Battery
Battery Charger Kit
Carrousel Stand
Certification
Note:
1. U.S. patents pending
2. Specifications are subject to change without prior notice

Appendix B : Tip Ejector Height Adjustment

Use a flat-head screw driver or other tool to turn the tip ejector height
adjustment screw as shown in Figure 15. By turning the screw in a
counter-clockwise direction, the tip ejector can be adjusted down. This
height adjustment feature enables efficient ejecting of different
manufacturer's tips.
Automatic Pipetting (AUTO), Multiple
Dispensing (MD), Mixing(MIX)
Sequential Aspirating/Dispensing (SE),
System Setup (SYS)
9 programs
5 speeds
Yes
High precision stepping motor
Yes, after 10 minutes
100/120/220/240 V AC-DC 3.6 V
Yes
Yes, lower manifold only
o
5 ~ 50 C
RH: 0 ~ 85%
900 mAh/3.6 V or above, Li-Ion
Optional
Optional
Complies with CE, Class A
(EN60101-1-2, EN50082-1, EN 55011)
Complies with ISO-8655/ DIN 12650
