4. LABNET Excel electronic pipettor Overview

This section presents an overview of the LABNET Excel electronic
pipettor's various components and buttons (see Figure 7) as well as the
symbols and indicators on the LCD display (see Figure 8).
(F r on t View)
Figure 7: 1-channel LABNET Excel electronic pipettor overview
LCD D ispla y
"R E S E T" Bu tton
Keypa d
Tip E jector
Bu sh in g
Lower P a r t
Tip F ittin g
(S id e View)
11
Ba tter y Cover
D C I n
"P LUNGE R " Bu tton
F in ger R est
Con n ector Nu t
