3.5.

Manual Blow-out Operation

The automatic blow-out function, in different pipetting modes, simulates
the blow-out function in manual pipettes. With the Blow-out function
selected, the user can press the PLUNGER button once to dispense the
liquid and the piston will travel an extra distance to blow out any remaining
liquid. The piston will then pause and return to its starting position.
Alernatively the user can press and hold the PLUNGER button to dispense.
The piston will travel the extra distance to blow out remaining liquid and
remain in that position until the plunger is released.
PLUNGER button is released, the piston will return back to its starting
position.
3.6.

Hanger Installation

The LABNET Excel electronic pipettor hanger can be attached to a shelf or
counter using the sticker as shown in Figure 6. The finger rest of the
LABNET Excel electronic pipettor locks into the hanger and keeps the
pipettor in a vertical position.
Figure 6: LABNET Excel electronic pipettor hanger installation
10
Only when the
