Reattach The Lower Piston Assembly - Labnet Excel E10-1 Operation Manual

Cylinder lock
Figure 13: Push the metal cylinder
lock downward until you hear a click
sound.

11.2. Reattach the lower piston assembly

Always remember to press
piston assembly of LABNET Excel electronic pipettor.
Follow these steps to reassemble LABNET Excel electronic pipettor:
1. Press the
PLUNGER
motor shaft retract about 1cm back into the handle. The step motor will
automatically retract inside if users do not touch any button for 10
minutes.
2. Connect the lower part with connecting nut. Tighten up the connecting
nut.
Figure 14: The lower piston
assembly will come off easily and
automatically.
RESET
button after you reattach the lower
button or any button of the keypad to make the step
28
