44 | Hardware Installation and Maintenance Guide for SG5700 Appliances
Callout Which ports are bonded
C Ports 1 and 3 are bonded together for the Client Network, if this network is used.
G Ports 2 and 4 are bonded together for the Grid Network.
This figure shows how the four 10/25-GbE ports are bonded in aggregate port bond mode.
Callout Which ports are bonded
1 All four ports are grouped in a single LACP bond, allowing all ports to be used for Grid
Network and Client Network traffic.
The table summarizes the options for configuring the four 10/25-GbE ports. The default settings are
shown in bold. You only need to configure the settings on the Link Configuration page if you want to
use a non-default setting.
